Frequently Asked Questions

1. What is the purpose of the 330130-045-01-CN?

It connects a 3300 XL proximity probe to a 3300 XL Proximitor® Sensor while preserving the calibrated electrical characteristics of the complete transducer system.

2. What does the "045" option indicate?

It specifies a 4.5-meter (14.8-foot) extension cable.

3. What does the "01" option mean?

It identifies the cable as an armored version, providing additional protection against abrasion, crushing, and mechanical damage.

4. What does the "CN" suffix indicate?

The CN suffix denotes the country-specific approval option for the China market. Depending on the product configuration, it may include applicable Chinese certification documentation such as NEPSI approvals where required.

5. Is this cable interchangeable with other 3300 XL extension cables?

Yes. It is designed for interchangeability within the 3300 XL 8 mm Proximity Transducer System, provided the correct cable length is selected to maintain the required total calibrated system length.

6. Why is the cable length important?

The probe, extension cable, and Proximitor® Sensor must be matched so their combined electrical length corresponds to the calibrated system length (typically 5 m or 9 m). This ensures specified measurement accuracy.

7. Does the armored construction affect electrical performance?

No. The armor provides mechanical protection while maintaining the electrical performance and calibration required for vibration monitoring applications.

8. Does it comply with API 670?

Yes. When used as part of a complete 3300 XL 8 mm Proximity Transducer System, it supports installations designed to meet API 670 requirements.
