Eddy-Current Proximity Probe for Machinery Protection and Condition Monitoring

The Bently Nevada 330101-00-24-10-12-CN is a 3300 XL 8 mm eddy-current proximity probe designed for non-contact measurement of shaft vibration, shaft position, and displacement in critical rotating machinery. It operates as part of the 3300 XL Proximity Transducer System, working with a compatible 3300 XL Proximitor® Sensor and extension cable. The 3300 XL system is designed to meet the performance requirements of API 670 for machinery protection applications.

Technical Specifications

Parameter	Specification
Product Type	Eddy-Current Proximity Probe
Manufacturer	Bently Nevada
Model	330101-00-24-10-12-CN
Product Series	3300 XL
Probe Diameter	8 mm
Thread Type	3/8-24 UNF (without armor)
Overall Case Length	2.4 in (61 mm)
Integral Cable Length	1.0 m (3.3 ft)
Connector Type	Miniature coaxial ClickLoc® connector
Cable Type	FluidLoc® cable
Agency Approval	CN (Country-specific approvals)

Typical Applications

Steam turbines
Gas turbines
Centrifugal compressors
Pumps
Electric motors
Fans and blowers
Gearboxes
Power generation facilities
Oil and gas processing plants
Industrial rotating machinery

Key Features

8 mm non-contact eddy-current sensing technology
Measures shaft vibration, displacement, and axial position
3/8-24 UNF threaded probe body
2.4 in (61 mm) probe case length
1.0 m integral FluidLoc® cable
Miniature ClickLoc® connector
CN country-specific approval option
Compatible with 3300 XL Proximitor® sensors
API 670 compliant when used as part of a complete 3300 XL transducer system
Designed for continuous industrial operation

Frequently Asked Questions

1. What is the 330101-00-24-10-12-CN used for?

It is used for non-contact measurement of shaft vibration, shaft position, and displacement in rotating machinery.

2. Which monitoring system is it compatible with?

It is designed for the Bently Nevada 3300 XL 8 mm Proximity Transducer System.

3. What is the probe diameter?

The probe has an 8 mm sensing tip.

4. What does the "24" option indicate?

It specifies an overall probe case length of 2.4 inches (61 mm).

5. What cable is included?

This model includes a 1.0 m FluidLoc® integral cable with a Miniature ClickLoc® connector.

6. What does the "12" option represent?

It specifies a Miniature ClickLoc® connector with FluidLoc® cable.

7. What does the "CN" approval option mean?

The CN suffix indicates country-specific approvals. Detailed certifications are listed in the Bently Nevada CN Approvals Quick Reference Guide.

8. Which industries commonly use this probe?

Power generation, oil and gas, petrochemical, mining, pulp and paper, and other industrial process industries.

9. Can it be used as a replacement probe?

Yes. It is suitable as a replacement probe for compatible Bently Nevada 3300 XL monitoring systems.

10. What are the main advantages of this probe?

It provides accurate, stable, non-contact shaft motion measurements for machinery protection, condition monitoring, and predictive maintenance.
