Yokogawa SBD4D-06 Digital terminal board

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa SBD4D-06 Digital terminal board

Name: Yokogawa SBD4D-06 Digital terminal board
Brand: Yokogawa Electric
SKU: 8908
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:SBD4D-06
Product Origin:Japan
Product Dimensions:130 × 50 × 30 mm
Product Weight:1kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Structured Field Wiring Interface for Reliable Industrial Automation Systems

The Yokogawa SBD4D-06 Digital Terminal Board is designed to provide a stable and well-organized interface for connecting field wiring to industrial control systems. It supports efficient signal distribution for digital I/O modules, helping simplify cabinet wiring architecture and improve system maintainability. With its robust industrial design and consistent connectivity performance, it is widely used in automation environments where structured wiring and reliable signal handling are essential.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa
Model Number	SBD4D-06
Product Type	Digital Terminal Board
Channel Capacity	16 Channels
Signal Type	Digital I/O Interface
Compatible Modules	SDV144 / SDV541
Mounting Type	DIN Rail Mount
Configuration	Single / Dual Redundant Support
Terminal Type	Industrial Screw Terminals
Rated Voltage	24 VDC
Rated Current	Up to 5 A
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Humidity Range	5% to 95% Non-Condensing
Dimensions	Approx. 130 × 50 × 30 mm
Weight	Approx. 0.30–2.5 kg (configuration dependent)
