Yokogawa SAV144-S33 Analog Input Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa SAV144-S33 Analog Input Module

Name: Yokogawa SAV144-S33 Analog Input Module
Brand: Yokogawa Electric
SKU: 8899
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:SAV144-S33
Product Origin:Japan
Product Dimensions:130 x 124x 32.8mm
Product Weight:0.29kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Yokogawa SAV144-S33 Analog Input Module is a high-reliability 16-channel voltage input module designed for ProSafe-RS safety instrumented systems (SIS) and CENTUM VP distributed control architectures. It is engineered to acquire precise analog voltage signals from field instruments and convert them into stable digital data for real-time process monitoring and safety logic execution.

With strong electrical isolation and SIL-oriented design principles, the SAV144-S33 is widely used in mission-critical industrial environments where measurement accuracy and system integrity directly impact plant safety and uptime.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa
Model Number	SAV144-S33
Product Type	Analog Input Module
System Compatibility	ProSafe-RS / CENTUM VP / FCS systems
Input Channels	16 isolated analog input channels
Input Signal Range	1–5 V DC / 1–10 V DC
Permissible Input Range	Up to ±30 V DC
Channel Configuration	Single-ended / differential (system dependent)
Input Impedance	~1 MΩ (powered state)
Accuracy	High-precision class (SIL-oriented measurement design)
Data Update Cycle	~40 ms typical
Isolation Voltage	Up to 1.5 kV AC
Power Consumption	~low-power module class (system supplied)
Wiring Interface	Terminal base / KS1 cable / system connector interface
Redundancy Support	Supported in dual-redundant configurations
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +85°C
Weight	~0.25–0.30 kg
Installation Type	FCU / ESB bus node mounting

Applications

The Yokogawa SAV144-S33 is widely used in safety-critical and high-availability industrial systems:

ProSafe-RS safety instrumented systems (SIS)
CENTUM VP distributed control systems (DCS)
Oil & gas refinery monitoring and shutdown systems
Petrochemical and chemical process automation
Power generation and turbine monitoring systems
Water treatment and utility control systems
Industrial SCADA data acquisition systems
High-integrity analog signal monitoring applications

Advantages

Provides 16-channel high-density isolated analog input capability
Designed for SIL-oriented safety system integration
Strong electrical isolation improves noise immunity in harsh environments
Stable long-term measurement performance with low drift characteristics
Supports redundant system architectures for higher availability
Flexible field wiring compatibility (terminal, KS1, system connectors)
Optimized for continuous 24/7 industrial operation
Seamless integration with Yokogawa CENTUM and ProSafe-RS platforms

Technical FAQs

Q1: What is the main function of SAV144-S33?
A: It converts analog voltage signals from field instruments into digital values for control and safety systems.

Q2: How many input channels does it support?
A: It supports 16 isolated analog input channels.

Q3: What signal types are supported?
A: 1–5 V DC and 1–10 V DC voltage signals.

Q4: Is it used in safety systems?
A: Yes, it is commonly used in ProSafe-RS SIS applications.

Q5: What is its maximum input tolerance?
A: It can tolerate up to approximately ±30 V DC.

Q6: Does it support redundancy?
A: Yes, dual-redundant configurations are supported.

Q7: What is its update speed?
A: Around 40 ms data refresh cycle.

Q8: What wiring methods are used?
A: Terminal base, KS1 signal cables, or system connector interfaces.

Q9: Where is it installed?
A: In Field Control Units (FCU) or ESB bus node systems.

Q10: Why is it important in DCS/SIS systems?
A: It ensures accurate and isolated analog signal acquisition for safe industrial process control.
