Yokogawa S2BN1D-12030 Base Plate With Disconnecting Terminal

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa S2BN1D-12030 Base Plate With Disconnecting Terminal

Name: Yokogawa S2BN1D-12030 Base Plate With Disconnecting Terminal
Brand: Yokogawa Electric
SKU: 8894
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:S2BN1D-12030
Product Origin:Japan
Product Dimensions:248 x 134 x 171.9 mm
Product Weight:1.4kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Yokogawa S2BN1D-12030 Base Plate with Disconnecting Terminal is a key hardware foundation module used in Yokogawa N-IO (Networked I/O) systems within CENTUM VP and ProSafe-RS distributed control architectures. It serves as the physical and electrical mounting platform for I/O modules, enabling safe signal distribution, field wiring termination, and system-level communication in high-availability industrial automation environments.

Designed for mission-critical process industries, this base plate integrates disconnecting terminal functionality, allowing individual channel isolation for maintenance, testing, and troubleshooting without disrupting overall system operation.

Technical Specifications

Parameter	Specification
Manufacturer	Yokogawa
Model Number	S2BN1D-12030
Product Type	Base Plate with Disconnecting Terminal
System Compatibility	Yokogawa CENTUM VP / ProSafe-RS / N-IO System
I/O Capacity	Up to 16 channels per base plate
Supported Modules	S2MMM843, S2MDV843 and compatible N-IO modules
Terminal Type	Disconnecting terminal block (field isolatable per channel)
Function	Field signal termination, power distribution, I/O module mounting
Redundancy Support	Supported in N-IO redundant configurations
Field Connection Types	Pressure clamp / spring clamp / cable connector variants
Field Power Supply	24 V DC (system supplied)
Isolation Voltage	Up to 1500 V AC (system design dependent)
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +85°C
Humidity Range	5–95% non-condensing
Mounting Type	DIN rail / cabinet mounting
System Bus	N-IO node interface bus (F-SB / Vnet/IP integration)
Weight	~2.5–3.5 kg (configuration dependent)
Dimensions (H×W×D)	~Standard rack-width N-IO base structure (system dependent)

Applications

The Yokogawa S2BN1D-12030 is widely used in advanced automation and safety-critical environments:

Yokogawa CENTUM VP distributed control systems
ProSafe-RS safety instrumented systems (SIS)
Oil & gas refinery control cabinets
Petrochemical and chemical process plants
Power generation and turbine control systems
LNG and offshore platform automation
Industrial process I/O marshalling systems
High-availability redundant control architectures

Advantages

Enables safe channel-level isolation for maintenance and diagnostics
Supports high-density modular I/O configuration (up to 16 channels)
Designed for mission-critical redundancy and continuous operation
Flexible field wiring options (pressure clamp, spring clamp, or connector-based)
Strong integration with Yokogawa N-IO distributed architecture
Improves maintenance efficiency by allowing individual channel disconnection
High electrical isolation enhances system safety and reliability
Optimized for large-scale industrial automation systems

Technical FAQs

Q1: What is the main function of the S2BN1D-12030 base plate?
A: It provides mounting, wiring termination, and signal distribution for N-IO modules in Yokogawa control systems.

Q2: What does “disconnecting terminal” mean?
A: It allows individual I/O channels to be electrically isolated for maintenance without shutting down the system.

Q3: How many channels does it support?
A: Up to 16 I/O channels per base plate configuration.

Q4: Which modules are compatible?
A: Modules such as S2MMM843 and S2MDV843 are commonly supported.

Q5: What systems use this base plate?
A: Yokogawa CENTUM VP and ProSafe-RS N-IO architectures.

Q6: Is it part of the control logic system?
A: No, it is a hardware interface and mounting platform, not a processing unit.

Q7: Can it support redundancy?
A: Yes, it is designed for redundant N-IO configurations.

Q8: What type of wiring is supported?
A: Pressure clamp, spring clamp, and cable connector-based field wiring.

Q9: What is its role in safety systems?
A: It ensures reliable signal isolation and structured I/O distribution in SIS environments.

Q10: Why is it important in DCS architecture?
A: It forms the physical backbone for safe, modular, and scalable I/O integration.
