Introduction
The ABB 1MRK001608-CAr02 Binary Input/Output Module is a high-performance industrial interface component designed for precise digital signal handling in ABB protection, control, and substation automation systems. It enables reliable acquisition of binary inputs and controlled relay outputs, ensuring fast and stable communication between field devices and intelligent control systems.
This module is widely used in ABB Relion®-based protection environments, where dependable switching logic, alarm processing, and interlocking functions are essential for electrical grid stability and industrial automation reliability.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
| Model Number | 1MRK001608-CAr02 |
| Product Type | Binary Input / Output Module |
| System Compatibility | ABB Relion / Substation Automation / IED systems |
| Function | Digital signal acquisition and relay output control |
| Input Channels | 16 digital inputs (typical configuration) |
| Output Channels | 8 digital relay outputs (typical configuration) |
| Input Voltage | 24 V DC |
| Output Voltage | 24 V DC / relay switching interface |
| Communication Protocols | IEC 61850, Modbus, DNP3 (system dependent) |
| Power Supply Range | 24–250 V DC / 48–240 V AC (system dependent) |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Isolation | Galvanic isolation between channels and system bus |
| Response Time | Millisecond-level switching performance |
| Mounting Type | Plug-in module for ABB protection IED chassis |
| Dimensions (H×W×D) | 120 mm × 100 mm × 60 mm |
| Weight | ~0.65 kg |
Applications
The ABB 1MRK001608-CAr02 module is designed for demanding power and automation environments where reliable binary control is essential:
-
Electrical substation protection and automation systems
-
ABB Relion® protection relay platforms
-
Circuit breaker control and interlocking systems
-
Power generation monitoring and control
-
Transmission and distribution grid automation
-
Industrial SCADA and RTU systems
-
Oil & gas electrical control networks
-
Process industry safety and alarm systems
Technical FAQs
Q1: What is the main function of this module?
A: It manages digital input signals and relay output control within ABB protection and automation systems.
Q2: Where is it typically used?
A: It is used in ABB Relion-based substation protection and control systems.
Q3: What voltage does it support?
A: It typically operates with 24 V DC inputs, with broader system-level power compatibility.
Q4: How many I/O points does it have?
A: It generally supports 16 inputs and 8 relay outputs depending on configuration.
Q5: Is it suitable for PLC systems?
A: It is primarily designed for ABB protection IED systems rather than general PLC use.
Q6: What industries use this module?
A: Power utilities, substations, oil & gas, and industrial automation sectors.
Q7: What is the response speed?
A: It operates at millisecond-level switching suitable for protection logic.
Q8: Can it control circuit breakers?
A: Yes, it is commonly used for breaker tripping and interlocking functions.
Q9: Is it resistant to electrical noise?
A: Yes, it is designed with strong EMI immunity for high-voltage environments.
Q10: What ensures its reliability?
A: ABB-grade design, galvanic isolation, and robust industrial construction ensure stable long-term operation.
