Overview of the Probe
The Bently Nevada 330901-00-16-05-02-CN 3300 NSv Proximity Probe is a compact eddy-current transducer designed for non-contact measurement of shaft vibration, shaft position, and displacement in rotating machinery. As a member of the 3300 NSv (Narrow Side View) Proximity Transducer System, this probe is specifically engineered for installations where space is limited and conventional proximity probes cannot be accommodated.
Its narrow-profile design makes it particularly suitable for small compressors, motors, gearboxes, and other machinery with restricted mounting clearances while maintaining the measurement accuracy required for machinery protection systems.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Bently Nevada |
| Model | 330901-00-16-05-02-CN |
| Product Type | 3300 NSv Proximity Probe |
| Measurement Technology | Eddy Current (Non-Contact) |
| Probe Style | Narrow Side View (NSv) |
| Unthreaded Length Option | 00 = 0.0 in |
| Case Length Option | 16 = 1.6 in |
| Total Length Option | 05 = 0.5 m (20 in) |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Cable Type | Standard Shielded Coaxial Cable |
| Thread Type | 1/4-28 UNF |
| Probe Housing Material | AISI 304 Stainless Steel |
| Probe Tip Material | PPS (Polyphenylene Sulfide) |
| Frequency Response | DC to 10 kHz |
| Operating Temperature | Up to approximately -35°C to +177°C (configuration dependent) |
| Agency Approval | CN = Country-Specific Approval Option |
| Probe Tip Diameter | 8 mm |
| Approximate Weight | 0.32–0.50 kg |
Typical Industrial Applications
The 330901-00-16-05-02-CN is widely used in machinery monitoring and protection systems, including:
-
Steam turbine vibration monitoring
-
Gas turbine protection systems
-
Centrifugal compressor monitoring
-
Industrial motor shaft displacement measurement
-
Gearbox condition monitoring
-
Pump vibration analysis
-
Power generation equipment protection
-
Oil & gas rotating asset monitoring
Its compact NSv design makes it especially valuable for installations where standard 8 mm proximity probes cannot fit.
Key Benefits
Space-Saving NSv Design
The narrow side-view configuration enables installation in confined machine spaces without compromising measurement performance.
High Measurement Accuracy
The probe delivers precise shaft displacement and vibration measurements, supporting reliable machinery diagnostics and protection.
Robust Industrial Construction
A stainless-steel housing and industrial-grade materials provide durability in demanding operating environments.
Strong Signal Stability
The shielded coaxial cable and ClickLoc connector help maintain stable signal transmission even in electrically noisy facilities.
Easy System Integration
The probe integrates seamlessly with compatible NSv extension cables and Proximitor sensors, simplifying installation and maintenance.
Technical FAQs
1. What does this probe measure?
It measures shaft vibration, shaft position, and displacement using eddy-current sensing technology.
2. Is it a contact sensor?
No. It operates as a non-contact proximity probe.
3. What does NSv mean?
NSv stands for Narrow Side View, a design optimized for installations with limited mounting space.
4. What is the total length of this configuration?
The "-05" option designates a total probe length of 0.5 meters (20 inches).
5. What does the "16" code represent?
It identifies a 1.6-inch overall case length.
6. What does the "CN" suffix indicate?
The CN option refers to a country-specific approval configuration.
7. Can the probe be used independently?
No. It must operate as part of a complete 3300 NSv transducer system with compatible extension cables and Proximitor sensors.
8. What industries commonly use this probe?
Power generation, oil and gas, petrochemical processing, manufacturing, and heavy industrial facilities.
9. What connector does it use?
It uses a miniature coaxial ClickLoc connector for secure installation.
10. Why choose an NSv probe instead of a standard proximity probe?
NSv probes are specifically designed for machinery with restricted installation clearances where standard probe geometries cannot be accommodated.
