Introduction
The Bently Nevada 330901-00-16-05-02-05 3300 NSv Proximity Probe is a precision eddy-current displacement sensor engineered for vibration and shaft position monitoring in rotating machinery. As part of the 3300 NSv (Narrow Side-View) transducer system, it is specifically designed for compact mechanical installations where standard probe geometries cannot fit, while still delivering highly stable and repeatable measurement performance.
This probe is widely used in turbines, compressors, pumps, and other critical rotating assets across power generation and heavy industrial environments. It supports early fault detection strategies by continuously monitoring shaft vibration and position with high accuracy and long-term stability.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Bently Nevada |
| Model | 330901-00-16-05-02-05 |
| Series | 3300 NSv Proximity Probe |
| Measurement Principle | Eddy current (non-contact displacement sensing) |
| System Requirement | Probe + extension cable + Proximitor sensor |
| Case Length Option | 1.6 in (code 16) |
| Unthreaded Length | 0.0 in |
| Total Cable Length | 0.5 m (system-dependent configuration) |
| Connector Type | Miniature coaxial ClickLoc |
| Thread Type | 1/4-28 UNF mounting |
| Housing Material | Stainless steel (industrial grade) |
| Cable Type | 75 Ω coaxial, FEP insulated |
| Operating Temperature | -40°C to +177°C |
| Weight | ~0.3–0.5 kg (typical configuration range) |
Applications
The 330901-00-16-05-02-05 is commonly deployed in condition monitoring systems for:
-
Gas and steam turbine vibration monitoring
-
Centrifugal compressor shaft displacement measurement
-
Industrial pump performance and health monitoring
-
Gearbox and drivetrain vibration diagnostics
-
Generator rotor stability monitoring
-
Oil & gas rotating machinery protection systems
-
API 670-compliant machinery protection systems
Its primary function is to detect early mechanical anomalies such as imbalance, misalignment, looseness, or bearing wear before they escalate into equipment failure.
Advantages
This NSv proximity probe is designed for high-reliability industrial environments where downtime is costly:
-
High-precision eddy-current sensing with stable long-term output
-
Compact side-view configuration for restricted installation areas
-
Strong EMI resistance in electrically noisy environments
-
Stainless steel construction for mechanical and corrosion durability
-
Stable signal transmission across full NSv system architecture
-
ClickLoc connector system for secure, vibration-resistant connections
-
Fully matched system calibration with NSv cables and Proximitor units
-
Proven reliability in global turbine and compressor fleets
In operation, it contributes directly to improved machine availability and safer plant operation by enabling early fault detection.
Technical FAQs
Q1: What is the main function of this probe?
A: It measures shaft vibration and radial displacement using eddy current technology.
Q2: Is it a contact sensor?
A: No, it is a non-contact proximity probe.
Q3: What system does it belong to?
A: The Bently Nevada 3300 NSv transducer system.
Q4: What does the “16” code mean?
A: It indicates a 1.6-inch case length configuration.
Q5: What is the cable length?
A: Approximately 0.5 meters depending on system configuration.
Q6: Can it operate alone?
A: No, it must be used with a matching extension cable and Proximitor sensor.
Q7: What is the operating temperature range?
A: Typically -40°C to +177°C depending on installation conditions.
Q8: Where is it commonly installed?
A: Turbines, compressors, pumps, and other rotating industrial machinery.
Q9: Is it interchangeable with other Bently Nevada probe series?
A: No, NSv components must remain within the NSv system family for correct calibration.
Q10: Why choose NSv over standard probes?
A: It is optimized for tight installation spaces with improved side-view sensing capability.
