Introduction
The Bently Nevada 330901-00-15-05-01-00 3300 NSv Proximity Probe is a high-precision eddy-current sensor designed for vibration and shaft position monitoring in rotating machinery. As part of the 3300 NSv Narrow Side-View transducer system, it is engineered for installations where space constraints prevent the use of standard proximity probes while still requiring high measurement accuracy and long-term stability.
This model is widely used in turbine systems, compressors, pumps, and critical rotating equipment where real-time displacement monitoring is essential for machinery protection and predictive maintenance strategies.
Technical Specifications
| Parameter | Details |
|---|
| Manufacturer | Bently Nevada |
| Model | 330901-00-15-05-01-00 |
| Series | 3300 NSv Proximity Probe |
| Measurement Principle | Eddy current (non-contact displacement sensing) |
| System Requirement | Probe + extension cable + Proximitor sensor |
| Case Length Option | 1.5 in (code 15) |
| Total Cable Length | 0.5 m (approx. 20 in system segment) |
| Unthreaded Length | 0.0 in |
| Connector Type | Miniature coaxial ClickLoc |
| Thread Type | 1/4-28 UNF (standard NSv mounting) |
| Housing Material | Stainless steel (industrial grade) |
| Cable Type | 75 Ω coaxial with FEP insulation |
| Operating Temperature | -40°C to +177°C (system dependent) |
| Weight | ~0.5 kg (approx., varies by configuration) |
Applications
The 330901-00-15-05-01-00 is widely deployed in industrial asset monitoring systems, including:
-
Gas and steam turbine vibration monitoring
-
Centrifugal compressor shaft displacement measurement
-
Industrial pump condition monitoring
-
Gearbox and drivetrain vibration analysis
-
Generator rotor stability monitoring
-
Oil & gas rotating machinery protection systems
-
API 670-compliant condition monitoring systems
Its primary role is to detect early mechanical deviation such as imbalance, misalignment, and bearing degradation.
Advantages
This NSv proximity probe is engineered for reliability in demanding industrial environments:
-
High-accuracy eddy current sensing for stable displacement readings
-
Compact side-view geometry for restricted installation spaces
-
Strong EMI resistance for noisy electrical environments
-
Robust stainless-steel construction for mechanical durability
-
Stable signal performance across long cable routing systems
-
ClickLoc connector system for secure, vibration-resistant installation
-
System-matched calibration with NSv extension cables and proximitor units
-
Field-proven reliability in global power and process industries
In practice, it delivers consistent performance in continuous-duty machinery protection systems where measurement drift is unacceptable.
Technical FAQs
Q1: What is the main function of this probe?
A: It measures shaft vibration and radial displacement using eddy current technology.
Q2: Is it a contact sensor?
A: No, it is a non-contact proximity probe.
Q3: What system does it belong to?
A: The Bently Nevada 3300 NSv transducer system.
Q4: What is the case length?
A: 1.5 inches (code 15 configuration).
Q5: What is the total cable length?
A: Approximately 0.5 meters.
Q6: Can it be used alone?
A: No, it must be used with a compatible NSv extension cable and proximitor sensor.
Q7: What is the operating temperature range?
A: Typically -40°C to +177°C depending on system setup.
Q8: Where is it commonly installed?
A: Turbines, compressors, pumps, and rotating industrial machines.
Q9: Is it interchangeable with other Bently Nevada series?
A: No, NSv components must remain within the same system family.
Q10: Why is it used instead of standard probes?
A: Its compact side-view design allows installation in very tight mechanical spaces.
