Stable 24V DC Supply Cable for ABB AC 800F / Freelance Systems
The ABB TK802F (3BDM000213R1) is a prefabricated industrial 24V DC supply cable designed for ABB AC 800F / Freelance distributed control systems (DCS). It is mainly used to connect power supply modules such as SD802F and SD812F, ensuring stable voltage delivery within automation cabinets.
Built for system-level integration rather than general wiring, this cable is optimized for safe, low-resistance power transmission and fast installation in industrial environments.
Technical Specifications
| Parameter | Details |
|---|
| Model | TK802F |
| Order Code | 3BDM000213R1 |
| Product Type | Prefabricated Power Supply Cable |
| Manufacturer | ABB |
| System Compatibility | ABB AC 800F / Freelance DCS |
| Application | 24V DC power distribution |
| Connected Modules | SD802F / SD812F |
| Cable Length | 2 meters |
| Voltage Rating | 24 V DC |
| Termination | Factory-fitted ferrules |
| Function | Power supply connection |
| Shielding | Industrial insulation / EMI resistance |
| Operating Temperature | -20°C to +60°C |
| Weight | ~0.1–1.1 kg (variant dependent) |
Industrial Applications
The ABB TK802F cable is commonly used in:
-
ABB AC 800F Freelance control systems
-
Distributed control system (DCS) cabinets
-
Industrial automation power distribution panels
-
Process industry control systems
-
Oil & gas and energy infrastructure automation
-
Manufacturing and production line control systems
-
Retrofit and legacy ABB installations
It is particularly important in environments where system uptime and wiring reliability directly affect production stability.
Key Advantages
-
Factory-prefabricated terminals reduce installation errors
-
Stable and safe 24V DC power transmission
-
Designed specifically for ABB AC 800F architecture
-
Fast plug-and-play installation
-
Improved control cabinet organization
-
High reliability for continuous 24/7 operation
-
Reduced maintenance complexity
These characteristics make it a trusted component in ABB industrial automation systems.
Technical FAQs
Q1: What is the ABB TK802F used for?
A: It is used to supply 24V DC power to ABB AC 800F system modules.
Q2: Which modules is it compatible with?
A: It is commonly used with SD802F and SD812F power supply units.
Q3: Is it a communication cable?
A: No, it is strictly a power supply cable, not a data cable.
Q4: What is its length?
A: The standard length is 2 meters.
Q5: Can it be replaced with a generic cable?
A: Not recommended, due to ABB-specific termination and system design requirements.
Q6: Is it shielded?
A: It uses industrial-grade insulation suitable for harsh environments.
Q7: What voltage does it support?
A: It is designed for 24V DC industrial power systems.
Q8: What is its main advantage?
A: It ensures stable and standardized power distribution in ABB control systems.
Q9: Is it still widely used today?
A: Yes, especially in ABB installed base and AC 800F systems.
Q10: Does it require configuration?
A: No, it is a passive prefabricated cable assembly.
