High-Voltage Energy Storage for Industrial Power Systems
The ABB 3BHB002000R0001 2uF 3100V Capacitor is a high-reliability industrial capacitor engineered for demanding power electronics and excitation system applications. Designed to operate under high-voltage conditions, this capacitor provides stable energy storage, rapid discharge capability, and dependable electrical performance in mission-critical automation environments.
Widely used in ABB UNITROL® excitation systems and industrial converter platforms, the module is optimized for long-term operational stability and efficient voltage management. Its compact construction and durable dielectric design make it suitable for continuous-duty industrial applications where precision and reliability are essential.
Technical Specifications
| Parameter | Details |
|---|
| Model | 3BHB002000R0001 |
| Product Type | High-Voltage Industrial Capacitor |
| Manufacturer | ABB |
| Capacitance | 2 µF |
| Rated Voltage | 3100V |
| Dielectric Material | Polypropylene Film |
| Product Family | UNITROL® Excitation Systems |
| Operating Temperature | -40°C to +85°C |
| Insulation Resistance | High industrial insulation performance |
| Mounting Type | Industrial panel / power system installation |
| Dimensions | Approx. 176 × 79.2 × 79.2 mm |
| Weight | Approx. 1 kg |
| Country of Origin | Switzerland / Germany |
| Application Category | Power electronics & excitation control |
Industrial Applications
The ABB 3BHB002000R0001 capacitor is commonly deployed in advanced industrial electrical systems, including:
-
ABB UNITROL® excitation systems
-
Industrial power converters
-
High-voltage drive systems
-
Power factor correction assemblies
-
Harmonic filtering systems
-
Energy storage and discharge circuits
-
Generator excitation platforms
-
Heavy industrial automation systems
Its high-voltage tolerance and stable energy discharge characteristics make it ideal for environments requiring dependable electrical regulation and continuous operational reliability.
Performance Advantages
The ABB 3BHB002000R0001 capacitor delivers several operational benefits for industrial power systems:
-
Reliable high-voltage energy storage capability
-
Stable electrical performance under demanding loads
-
Compact industrial construction for efficient integration
-
Excellent thermal resistance for continuous operation
-
Long operational lifespan reducing maintenance frequency
-
Fast discharge response supporting excitation systems
-
Strong compatibility with ABB power platforms
-
Industrial-grade dielectric stability improving system safety
These advantages help improve system efficiency while supporting stable power regulation in critical automation applications.
Technical FAQs
Q1: What is the capacitance value of the ABB 3BHB002000R0001?
A: The capacitor is rated at 2 µF.
Q2: What is the rated operating voltage?
A: It is designed for high-voltage applications up to 3100V.
Q3: Which ABB systems commonly use this capacitor?
A: It is commonly used in ABB UNITROL® excitation and industrial power systems.
Q4: What dielectric material is used?
A: Polypropylene film dielectric material is commonly referenced for this capacitor type.
Q5: What are the approximate dimensions?
A: The capacitor measures approximately 176 × 79.2 × 79.2 mm.
Q6: What is the approximate net weight?
A: The net weight is approximately 1 kg.
Q7: Can it operate in harsh industrial environments?
A: Yes, it is engineered for industrial environments involving thermal stress and electrical load fluctuations.
Q8: What is the operating temperature range?
A: Typical industrial operation ranges from approximately -40°C to +85°C.
Q9: Is this capacitor suitable for power factor correction systems?
A: Yes, it is commonly used in power electronics and power factor correction applications.
Q10: Why is this capacitor valued in industrial automation?
A: Its high-voltage durability, stable energy storage capability, and ABB system compatibility make it highly reliable for industrial power control applications.
