Precision Voltage Scaling Solution for Medium-Voltage Industrial Drive Systems
The ABB XV C722 A02 3BHB002751R0102 Voltage Measurement Card is a high-accuracy industrial measurement module developed for voltage sensing, signal scaling, and monitoring applications in ABB medium-voltage drive and automation systems. Engineered for demanding industrial environments, this card provides stable and precise voltage feedback to control systems, helping maintain operational safety, power stability, and efficient system regulation.
Designed with ABB’s industrial-grade electronic architecture, the XV C722 A02 supports reliable integration into power conversion and automation platforms where accurate electrical measurement is critical for process control and protection functions.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
| Model | XV C722 A02 |
| Part Number | 3BHB002751R0102 |
| Product Type | Voltage Measurement Card |
| ABB Designation | SVA 3k3V |
| Main Function | Voltage Measurement & Scaling |
| Application Type | Medium-Voltage Drive Systems |
| Input Voltage Range | Up to 3000V industrial measurement range |
| Output Signal Range | 0–10V scaled control signal |
| Measurement Accuracy | High-precision industrial scaling |
| Installation Type | Rack / Cabinet Mounted |
| Communication Interface | ABB industrial control integration |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Country of Origin | Switzerland |
Industrial Applications
The ABB XV C722 A02 Voltage Measurement Card is widely utilized in industrial power systems requiring stable voltage monitoring and accurate signal scaling for automation control. Its measurement precision helps maintain reliable system feedback in high-power environments.
Typical applications include:
-
Medium-voltage drive systems
-
Industrial power converters
-
Electrical monitoring platforms
-
Power generation systems
-
Energy distribution infrastructure
-
Industrial motor control systems
-
High-power inverter applications
-
Process automation and protection systems
Its reliable scaling capability supports real-time voltage supervision and improved operational safety in critical industrial processes.
Key Product Advantages
High-Precision Voltage Measurement
Engineered to deliver accurate voltage sensing and stable scaling performance for industrial automation systems.
Reliable Signal Conversion
Converts high-voltage input signals into controlled output values suitable for monitoring and control applications.
Industrial-Grade Stability
Built for continuous operation in electrically demanding industrial environments.
Compact Installation Design
The compact module structure allows efficient integration into ABB drive cabinets and automation racks.
Strong System Compatibility
Optimized for ABB medium-voltage drive and control architectures, enabling seamless integration.
Enhanced Operational Protection
Supports voltage supervision functions that contribute to safer and more stable system operation.
Technical FAQs
1. What is the primary function of the ABB XV C722 A02 module?
It measures and scales industrial voltage signals for monitoring and automation control systems.
2. Is this card suitable for medium-voltage applications?
Yes, it is specifically designed for ABB medium-voltage industrial systems.
3. What is the input voltage capability?
The module supports industrial voltage measurement applications up to approximately 3000V.
4. What industries commonly use this module?
Power generation, heavy manufacturing, automation, and energy infrastructure industries commonly use this card.
5. Does the module provide accurate voltage scaling?
Yes, it is engineered for high-precision voltage measurement and scaling performance.
6. Can the card operate continuously in industrial environments?
Yes, it is designed for stable long-term industrial operation.
7. Is it compatible with ABB drive systems?
Yes, it integrates efficiently within ABB drive and automation platforms.
8. Does the module support control system feedback?
Yes, it provides scaled voltage signals for monitoring and process regulation functions.
9. Is installation complicated?
No, it supports standard rack or cabinet integration for industrial systems.
10. Does the module improve system safety?
Yes, accurate voltage monitoring helps improve electrical protection and operational stability.
