Schneider Electric 140XTS00100 Terminal Block – Modicon Quantum Series (40-Point I/O Interface Block)
The Schneider Electric 140XTS00100 Terminal Block is a high-reliability wiring accessory designed for the Modicon Quantum automation platform. It provides a structured and secure interface for connecting field I/O signals to PLC modules, ensuring stable signal transmission and organized cabinet wiring in industrial control systems.
Engineered for demanding automation environments, this 40-point terminal block is widely used in process control, infrastructure systems, and large-scale industrial applications where wiring clarity, signal integrity, and maintenance efficiency are critical.
Technical Specifications
The 140XTS00100 is designed to simplify I/O wiring while maintaining robust industrial performance.
| Parameter | Specification |
|---|
| Manufacturer | Schneider Electric |
| Series | Modicon Quantum |
| Model | 140XTS00100 |
| Product Type | Terminal Block (I/O Interface) |
| Connection Points | 40 terminals |
| Compatibility | Modicon Quantum I/O modules |
| Mounting Type | Direct mounting in control cabinet |
| Protection Rating | IP20 (finger-safe design) |
| Wiring Type | Screw terminal connection |
| Application Category | PLC I/O interface accessory |
Industrial Applications
The 140XTS00100 terminal block is used in complex automation environments where large numbers of I/O signals must be managed safely and efficiently.
Typical applications include:
-
PLC-based industrial control systems
-
Process automation plants
-
Water treatment systems
-
Energy and power distribution control
-
Petrochemical and refinery automation
-
Manufacturing line control cabinets
-
Infrastructure automation systems
It is especially valuable in systems requiring structured wiring, fast troubleshooting, and long-term reliability.
Key Advantages
Organized I/O Wiring Architecture
Provides a clean and structured connection interface between field devices and PLC modules, reducing wiring complexity.
High Signal Reliability
Stable screw-terminal design ensures secure electrical contact and reduces the risk of signal interruption.
Industrial-Grade Compatibility
Designed specifically for the Modicon Quantum PLC ecosystem, ensuring seamless integration with existing automation architectures.
Maintenance Efficiency
Clear terminal layout simplifies diagnostics, replacement, and long-term system maintenance.
Compact Cabinet Integration
Space-efficient design supports high-density control panel configurations without clutter.
Durable Industrial Construction
Built for long service life in continuous industrial environments with stable mechanical and electrical performance.
Technical FAQs
1. What is the main function of the 140XTS00100?
It connects field I/O wiring to Modicon Quantum PLC modules in a structured and safe way.
2. How many connection points does it have?
It provides 40 terminal connection points for I/O signals.
3. What PLC system is it compatible with?
It is designed for the Schneider Modicon Quantum platform.
4. What is its protection rating?
It has an IP20 rating, suitable for installation inside control cabinets.
5. What type of connection does it use?
It uses screw-type terminal connections for secure wiring.
6. What is its weight?
Approximately 0.19–0.20 kg.
7. What are its dimensions?
Around 205 × 50 × 50 mm.
8. Is it suitable for industrial environments?
Yes, it is designed for heavy-duty industrial automation systems.
9. Does it support analog and digital signals?
Yes, it supports both analog and discrete I/O module connections.
10. What is its main advantage in automation systems?
It simplifies wiring architecture while improving reliability and maintenance efficiency.
