Connection Module
The Schneider Electric 170XTS00501 Busbar 2 Rows is a robust connection accessory designed for the Modicon Momentum automation platform. It plays a critical role in simplifying field wiring by providing a centralized and reliable power and signal distribution interface for I/O bases. Engineered for industrial-grade automation environments, this busbar enhances wiring efficiency, reduces installation complexity, and ensures stable electrical connectivity across control systems.
This component is widely used in modern industrial automation systems where compact design, wiring clarity, and operational reliability are essential.
Technical Specifications
The 170XTS00501 is built for structured electrical distribution in PLC-based architectures, especially within distributed I/O setups.
| Parameter | Specification |
|---|
| Manufacturer | Schneider Electric |
| Product Series | Modicon Momentum |
| Part Number | 170XTS00501 |
| Module Type | Busbar (2 Rows) |
| Connection Type | Screw-type terminals |
| Application Base | Analog & Discrete I/O base |
| Number of Rows | 2 |
| Function | Common field device connection & power distribution |
| Electrical Role | Protective distribution interface |
| Mounting Style | Panel / base-mounted accessory |
Applications
The 170XTS00501 busbar is commonly deployed in:
-
Industrial PLC control panels
-
Distributed I/O systems in manufacturing lines
-
Packaging and material handling automation
-
Textile and process automation equipment
-
Electrical distribution inside modular control architectures
It is especially useful where multiple field devices must be connected to a unified grounding and power distribution structure, improving wiring clarity and system maintainability.
Advantages
-
Streamlined Wiring Architecture – Reduces clutter inside control cabinets
-
High System Reliability – Ensures stable electrical distribution across I/O modules
-
Compact Industrial Design – Optimized for space-constrained automation panels
-
Maintenance-Friendly Layout – Simplifies troubleshooting and replacement
-
Robust Industrial Construction – Designed for long-term operation in demanding environments
-
Improved Safety Structure – Helps organize protective distribution pathways
This component is often preferred in high-density automation systems where uptime and wiring precision are critical.
Technical FAQs
1. What is the main function of the 170XTS00501?
It provides a shared electrical connection point for field devices in I/O systems.
2. Which platform is it compatible with?
It is designed for the Modicon Momentum automation platform.
3. How many rows does it support?
It supports a 2-row configuration.
4. What type of terminals are used?
It uses screw-type terminals for secure connections.
5. What is its primary application?
It is used for distributing power and signals to discrete and analog I/O bases.
6. Is it suitable for industrial environments?
Yes, it is engineered for industrial automation applications.
7. What is its approximate weight?
Around 64 grams depending on configuration.
8. Does it improve wiring efficiency?
Yes, it significantly reduces wiring complexity and improves cabinet organization.
9. Can it be used in retrofit systems?
Yes, it is often used in system upgrades and replacements.
10. Is it still actively produced?
Some sources indicate it has been discontinued in certain regions, but remains widely used in legacy systems.
