Introduction
The Yokogawa F3PU10-0S Power Supply Module is a core power unit designed for FA-M3 PLC systems, delivering stable and regulated DC power to CPU, I/O, and communication modules within the controller rack. It is engineered for industrial environments where continuous operation, electrical stability, and system protection are essential for reliable automation performance.
As part of the FA-M3 modular architecture, this power supply ensures consistent energy distribution across all connected modules, forming the foundation of a stable and scalable PLC system. Its compact design and high-efficiency output make it a widely adopted choice in factory automation applications.
Technical Specifications
| Parameter | Specification |
|---|
| Model | F3PU10-0S |
| Module Type | Power Supply Module |
| Series | FA-M3 |
| Input Voltage | 100–240 V AC (50/60 Hz) |
| Output Voltage | 5 V DC |
| Rated Output Current | 2.0 A |
| Output Capacity | Suitable for 4–6 slot base units |
| Power Consumption | Approx. 35 VA |
| Installation Type | FA-M3 base unit mounted |
| Connection Type | Terminal screw (M4) |
| Protection Functions | Overcurrent, overvoltage, short-circuit protection |
| Cooling Method | Natural air cooling |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 75°C |
| Humidity | 10–90% RH (non-condensing) |
| Dimensions (W × H × D) | Approx. 28.9 × 100 × 106 mm |
| Weight | Approx. 0.3 kg |
Applications
The F3PU10-0S is widely used in small to medium-scale FA-M3 PLC systems where stable and efficient power distribution is required. Typical applications include:
-
Compact industrial automation panels
-
Machine-level control systems
-
Packaging and assembly equipment
-
Conveyor and material handling systems
-
Factory equipment control cabinets
-
Distributed small-scale PLC installations
It is especially suitable for systems with limited module slots requiring reliable power stability.
Advantages
One of the key advantages of the F3PU10-0S is its stable 5 V DC regulated output, ensuring consistent power delivery to sensitive PLC components such as CPUs and communication modules.
It supports a wide input voltage range (100–240 V AC), allowing flexible installation in global industrial environments without additional configuration.
The module is designed with built-in electrical protection functions, including overcurrent and short-circuit protection, improving system safety and long-term reliability.
Its compact form factor for 4–6 slot base units makes it ideal for space-constrained control cabinets while maintaining high operational stability.
Additionally, it integrates seamlessly into the FA-M3 system architecture, ensuring synchronized power distribution across all connected modules.
Technical FAQs
1. What is the main function of the F3PU10-0S?
It supplies regulated 5 V DC power to FA-M3 PLC modules.
2. What is the input voltage range?
100–240 V AC, suitable for global industrial use.
3. What systems is it compatible with?
It is designed for Yokogawa FA-M3 PLC platforms.
4. How many slots can it support?
It is intended for 4–6 slot base modules.
5. Does it include protection features?
Yes, it includes overcurrent and short-circuit protection.
6. What is the output current capacity?
2.0 A at 5 V DC.
7. Is it fan-cooled?
No, it uses natural air cooling.
8. Can it be used in harsh environments?
Yes, it is designed for industrial temperature and humidity conditions.
9. What type of mounting does it use?
It mounts directly onto the FA-M3 base unit.
10. Is it suitable for continuous operation?
Yes, it is designed for 24/7 industrial automation use.
