Introduction
The Schneider 140NOE35100C Ethernet SY/MAX Fiber Optic Module is a high-reliability communication interface designed for the Modicon Quantum automation platform. It enables seamless integration between Quantum PLC systems and SY/MAX-based networks using fiber optic Ethernet technology. Built for industrial environments where long-distance communication and strong electrical noise immunity are required, this module ensures stable and secure data transmission across distributed control systems.
It is commonly used in legacy industrial infrastructures that still rely on SY/MAX communication protocols but require modern Ethernet-based connectivity upgrades.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Ethernet SY/MAX Fiber Optic Communication Module |
| Platform | Modicon Quantum |
| Communication Type | SY/MAX Ethernet over Fiber Optic |
| Network Standard | 10BASE-FL (Fiber Optic Ethernet) |
| Interface Type | Dual fiber optic ST connectors |
| Communication Channels | 1 Ethernet SY/MAX channel |
| Data Rate | 10 Mbps |
| Cable Type | Multimode fiber optic |
| Backplane Support | Quantum rack integration |
| Power Consumption | Approx. 1000 mA via backplane |
| Isolation | High EMI immunity (fiber-based) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
Applications
The 140NOE35100C is widely used in industrial systems where reliable long-distance communication is required between PLCs and remote devices. Typical applications include:
-
Large manufacturing plants with distributed control systems
-
Power generation and electrical substations
-
Water and wastewater treatment facilities
-
Industrial automation networks using SY/MAX legacy systems
-
Process industries requiring EMI-resistant communication links
Its fiber optic design makes it especially suitable for environments with high electromagnetic interference or where copper cabling is not practical.
Advantages
This module delivers a strong combination of legacy compatibility and modern communication reliability. Its primary advantage is fiber optic transmission, which provides excellent resistance to electromagnetic interference and enables long-distance communication without signal degradation.
It supports SY/MAX Ethernet integration, allowing older industrial systems to remain operational while benefiting from Ethernet-based networking. This reduces the need for full system replacement, protecting existing infrastructure investments.
The dual ST fiber ports ensure stable and redundant physical connectivity, while Quantum backplane integration simplifies installation within existing PLC racks. Its rugged industrial design ensures consistent performance in harsh environments with temperature fluctuations and electrical noise.
Technical FAQs
1. What is the main function of the 140NOE35100C module?
It enables SY/MAX Ethernet communication over fiber optic networks in Modicon Quantum systems.
2. What type of fiber connection does it use?
It uses 10BASE-FL fiber optic Ethernet with ST connectors.
3. What is its communication speed?
It operates at 10 Mbps.
4. Is it compatible with SY/MAX systems?
Yes, it is specifically designed for SY/MAX Ethernet integration.
5. How many fiber ports does it have?
It typically includes dual fiber optic ports (TX/RX).
6. What PLC platform does it support?
It is designed for Modicon Quantum PLC systems.
7. What is its main advantage over copper Ethernet modules?
Higher EMI immunity and longer communication distance using fiber optics.
8. Is it suitable for modern Ethernet networks?
It is mainly intended for SY/MAX and legacy industrial Ethernet systems.
9. How is it powered?
Through the Quantum rack backplane power supply.
10. What industries commonly use it?
Energy, manufacturing, utilities, and process automation industries.
