Introduction
The ABB PDP800 Profibus DP V0/V1/V2 Master Module is a high-performance communication interface designed to connect ABB control systems—such as Symphony Plus—with PROFIBUS field networks. Acting as a master node, it enables seamless communication with distributed devices, ensuring reliable data exchange between controllers and field equipment.
Built for modern industrial automation, the PDP800 supports advanced PROFIBUS protocols (V0, V1, and V2), making it suitable for both cyclic and acyclic data communication, as well as time-critical applications. Its robust architecture ensures stable operation in complex and large-scale industrial environments.
Technical Specifications
| Parameter | Details |
|---|
| Model | PDP800 |
| Manufacturer | ABB |
| Module Type | Communication Module (Profibus DP Master) |
| Protocol Support | PROFIBUS DP V0 / V1 / V2 |
| Max Data Rate | Up to 12 Mbps |
| Max Slave Devices | Up to 125 devices |
| Communication Media | Copper / Fiber optic |
| Operating Voltage | 24 V DC |
| Timestamp Capability | 1 ms (DP V2) |
| System Integration | Symphony Plus / S800 I/O |
| Operating Temperature | -20°C to +70°C |
| Protection Rating | IP20 (module level) |
| Dimensions | 243.84 × 170.18 × 73.66 mm |
| Weight | Approx. 0.2 – 1.5 kg |
Applications
The PDP800 is widely deployed in industrial environments where reliable fieldbus communication is critical. Typical applications include:
-
Power generation and turbine control systems
-
Oil & gas process automation
-
Chemical and petrochemical plants
-
Distributed control systems (DCS)
-
Integration of smart field devices (IEDs, transmitters, actuators)
-
Large-scale manufacturing automation
It is particularly valuable in systems requiring communication with multiple distributed devices across long distances, including fiber-optic PROFIBUS networks.
Advantages
The PDP800 stands out for its multi-protocol PROFIBUS support, enabling both real-time cyclic data exchange (V0) and advanced diagnostics or parameterization (V1/V2). This flexibility allows engineers to design highly responsive and intelligent automation systems.
Its ability to support up to 125 slave devices significantly reduces network complexity, making it ideal for large distributed architectures. Additionally, the module supports long-distance communication via fiber optics—up to several kilometers—enhancing deployment flexibility in large plants.
Another key advantage is its tight integration with ABB Symphony Plus systems, enabling efficient configuration, diagnostics, and data sharing across the entire control network. This reduces engineering time and improves system transparency.
Overall, it delivers a combination of speed, scalability, and reliability, making it a cornerstone communication module for ABB-based automation systems.
Technical FAQs
1. What is the primary function of the PDP800 module?
It acts as a PROFIBUS DP master, enabling communication between ABB controllers and field devices.
2. Which PROFIBUS versions are supported?
It supports DP V0, V1, and V2 protocols.
3. How many devices can it connect to?
Up to 125 slave devices can be connected.
4. What is the maximum communication speed?
Up to 12 Mbps data transfer rate.
5. Does it support fiber optic communication?
Yes, it supports both copper and fiber optic PROFIBUS links.
6. What systems is it compatible with?
It integrates with ABB Symphony Plus and S800 I/O systems.
7. Can it handle time-critical applications?
Yes, DP V2 support allows precise time stamping and synchronization.
8. What types of devices can it connect to?
Transmitters, actuators, motor control centers, and intelligent electronic devices.
9. Is it suitable for large industrial plants?
Yes, its scalability and long-distance communication make it ideal for large systems.
10. How is it installed?
It is mounted within ABB control system racks or cabinets as part of the communication infrastructure.
