The ABB Bailey NTDI01 6632113A1 Digital I/O Termination Unit is a high-reliability interface component designed for legacy INFI 90 and Symphony Distributed Control Systems (DCS). It serves as a critical signal termination and distribution hub, ensuring stable and organized connection between field devices and control system I/O modules.
Built for industrial-grade automation environments, this unit is widely appreciated for its long service life, clean wiring architecture, and dependable signal integrity in demanding process control applications. Whether used in modernization projects or system maintenance, the NTDI01 remains a trusted backbone component in ABB Bailey installations.
Technical Specifications
The NTDI01 is engineered with a compact yet robust structure optimized for cabinet-level integration.
| Parameter | Specification |
|---|
| Model | NTDI01 |
| Part Number | 6632113A1 |
| Manufacturer | ABB Bailey |
| Function | Digital I/O Termination Unit |
| System Compatibility | INFI 90 / Symphony DCS |
| Signal Type | Digital (Discrete I/O) |
| Channel Capacity | Up to 16 I/O points |
| Mounting Type | Panel / Cabinet mounted |
| Terminal Type | Industrial screw terminals |
| Operating Temperature | -20°C to +60°C |
| Dimensions (W × H × D) | 78.74 × 233.68 × 213.36 mm |
| Weight | ~0.36 kg |
| Housing Material | Industrial-grade composite & metal frame |
Applications
The NTDI01 is widely used in industrial distributed control systems where reliable digital signal handling is essential:
-
Oil & gas production and pipeline control systems
-
Power generation and turbine automation
-
Petrochemical and refinery control systems
-
Water and wastewater treatment plants
-
Industrial manufacturing automation lines
-
Legacy ABB INFI 90 system maintenance and upgrades
It is especially valuable in installations requiring clean, organized, and interference-resistant digital I/O wiring structures.
Advantages
The ABB Bailey NTDI01 stands out as a premium termination solution in legacy DCS ecosystems:
-
Stable Signal Integrity – minimizes noise and ensures clean digital signal transmission
-
Efficient Wiring Architecture – structured terminal layout simplifies installation and maintenance
-
High Durability Design – built for continuous operation in harsh industrial environments
-
Space-Saving Form Factor – compact footprint ideal for dense control cabinets
-
Low Maintenance Requirement – passive design reduces failure points and service needs
-
Seamless System Integration – optimized for ABB INFI 90 and Symphony platforms
-
Engineering-Friendly Layout – clearly organized terminals improve commissioning efficiency
Technical FAQs
1. What is the primary function of NTDI01?
It provides termination and distribution for digital I/O signals in ABB INFI 90 systems.
2. Is the NTDI01 an active or passive module?
It is a passive termination unit with no processing electronics.
3. How many I/O channels does it support?
Typically up to 16 discrete digital signal points.
4. What systems is it compatible with?
ABB Bailey INFI 90 and Symphony DCS platforms.
5. Can it handle analog signals?
No, it is designed specifically for digital I/O termination.
6. What is its operating temperature range?
Approximately -20°C to +60°C depending on installation conditions.
7. What is the installation method?
It is mounted inside control cabinets using panel or DIN-style arrangements.
8. What is the weight of the unit?
Around 0.36 kg in standard configuration.
9. Does it require software configuration?
No configuration is required as it is a hardware termination device.
10. What makes it reliable in industrial use?
Its passive design, robust terminals, and industrial-grade construction ensure long-term stability.
