Emerson KJ3225X1-BA1 12P4174X032 Resistance Input Card

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Emerson KJ3225X1-BA1 12P4174X032 Resistance Input Card

Name: Emerson KJ3225X1-BA1 12P4174X032 Resistance Input Card
Brand: Emerson Module
SKU: 6663
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Emerson Module
Item No.:KJ3225X1-BA1 12P4174X032
Product Origin:USA
Product Dimensions:44 × 108 × 114 mm
Product Weight:0.25kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

High-Precision Resistance Measurement for DeltaV™ Systems

The Emerson KJ3225X1-BA1 12P4174X032 Resistance Input Card is a specialized analog input module designed for accurate acquisition of resistance-based signals, such as RTDs and thermistors, in DeltaV™ distributed control systems. This module converts resistance values into precise digital signals, providing reliable temperature and sensor measurements for critical industrial processes.

Its robust design ensures stable operation even in harsh environments, while compact dimensions allow integration into standard DeltaV I/O racks, optimizing cabinet space and simplifying system expansion.

Technical Specifications

Parameter	Specification
Product Series	DeltaV™ Distributed Control System
Model	KJ3225X1-BA1
Part Number	12P4174X032
Module Type	Resistance Input Module
Input Channels	8 RTD / resistance channels
Supported Sensor Types	PT100, PT1000, Ni100, Ni1000, Thermistor
Input Range	0–400 Ω (typical, depends on sensor)
Accuracy	±0.1% full scale
Communication Protocol	DeltaV internal bus
Power Supply	12 VDC LocalBus / 24 VDC field power
Operating Temperature	-40 °C to +70 °C
Relative Humidity	5–95% non-condensing
Dimensions (H × W × D)	Approx. 44 × 108 × 114 mm
Weight	Approx. 0.25 kg

Applications

The KJ3225X1-BA1 is ideal for industries and processes where precise resistance-based measurements are required:

Temperature monitoring in chemical and petrochemical plants
Oil & gas production for critical process measurements
Power generation facilities for thermal monitoring
Water and wastewater systems using RTDs for level and temperature sensing
Food and pharmaceutical production requiring high-accuracy sensor input

Its high-precision measurement ensures consistent process control and enhanced safety monitoring.

Key Advantages

High Accuracy: ±0.1% full-scale conversion ensures precise measurement.
Multiple Sensor Compatibility: Supports PT100, PT1000, Ni100, Ni1000, and thermistors.
Industrial Durability: Operates reliably in extreme temperatures and humidities.
Compact & Modular: Fits standard DeltaV racks, minimizing cabinet footprint.
Simplified Integration: Works seamlessly with DeltaV distributed control architecture.

This module allows operators to obtain reliable resistance readings, facilitating accurate process control and predictive maintenance.

Technical FAQs

How many input channels does the card have?
8 resistance input channels.
Which sensor types are supported?
PT100, PT1000, Ni100, Ni1000, and thermistors.
What is the typical accuracy?
±0.1% full-scale.
What is the operating temperature range?
-40 °C to +70 °C.
Is it compatible with DeltaV Series 2 systems?
Yes, fully compatible.
What power does it require?
12 VDC LocalBus and 24 VDC field power.
Does it support hot-swap replacement?
Yes, modules can be replaced without shutting down the system.
Can it operate in humid environments?
Yes, up to 95% non-condensing humidity.
What is the module’s weight and dimensions?
Approx. 0.25 kg; 44 × 108 × 114 mm.
Which industries commonly use this module?
Chemical, petrochemical, oil & gas, power generation, water/wastewater, and food/pharma.
