Ovation 5X00622G01 16-Channel RTD Input Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Ovation 5X00622G01 16-Channel RTD Input Module

Name: Ovation 5X00622G01 16-Channel RTD Input Module
Brand: Ovation DCS
SKU: 6447
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Ovation DCS
Item No.:5X00622G01
Product Origin:USA
Product Dimensions:120 × 30 × 95 mm
Product Weight:0.55kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Precision Temperature Acquisition for Critical Processes

The Ovation 5X00622G01 16-Channel RTD Input Module is purpose-built for high-accuracy temperature measurement in Emerson Ovation Distributed Control Systems (DCS). Designed to convert resistance signals from RTD sensors into precise digital values, this module enables real-time monitoring and control of temperature-sensitive processes.

With support for multiple RTD types and advanced signal conditioning, the 5X00622G01 ensures reliable data acquisition even in electrically noisy and harsh industrial environments. Its high channel density and robust design make it a preferred choice for large-scale process automation systems.

Technical Specifications

Parameter	Specification
Manufacturer	Emerson Ovation
Model	5X00622G01
Module Type	RTD Input Module
Input Channels	16 isolated RTD channels
Supported RTD Types	Pt100, Pt500, Pt1000, Ni120, Cu100
Wiring Types	2-wire, 3-wire, 4-wire RTD
Temperature Range	–200 °C to +800 °C
Accuracy	±0.1 % of full scale
Resolution	0.01 °C
Excitation Current	~0.5 mA (low self-heating)
Isolation	Channel-to-channel and system isolation
Communication	Ovation backplane integration
Power Supply	24 V DC (via rack/backplane)
Diagnostics	Open-circuit detection, alarm functions
Operating Temperature	–20 °C to 60 °C
Storage Temperature	–40 °C to 85 °C
Humidity	Up to 95 % non-condensing
Dimensions (HxWxD)	Approx. 120 × 30 × 95 mm
Weight	Approx. 0.55 kg
Mounting	Rack slot installation

Applications

The 5X00622G01 is widely used in industries where accurate temperature monitoring is essential for safety, efficiency, and quality control:

Power generation turbines and boiler monitoring
Chemical and petrochemical process control
Oil & gas temperature sensing systems
Water and wastewater treatment facilities
Manufacturing processes requiring multi-point temperature feedback

Advantages

High Measurement Accuracy: Delivers precise temperature readings critical for process stability.
Flexible RTD Compatibility: Supports a wide range of RTD sensor types and wiring configurations.
16-Channel Density: Enables efficient multi-point temperature monitoring within a single module.
Advanced Diagnostics: Detects wiring faults and abnormal conditions to improve system reliability.
Noise Immunity: Isolation design minimizes interference and ensures signal integrity.
Seamless Integration: Fully compatible with Ovation DCS for real-time control and monitoring.

Technical FAQs

1. What type of sensors does this module support?
It supports multiple RTD types including Pt100, Pt500, Pt1000, Ni120, and Cu100.

2. How many input channels are available?
The module provides 16 independent RTD input channels.

3. What temperature range can it measure?
It covers a wide range from –200 °C to +800 °C depending on RTD type.

4. What level of accuracy does it offer?
Typical accuracy is ±0.1 % of full scale.

5. Does it support different wiring methods?
Yes, it supports 2-wire, 3-wire, and 4-wire RTD configurations.

6. Is channel isolation provided?
Yes, channel or group isolation enhances noise immunity.

7. What diagnostic features are included?
It includes open-circuit detection and alarm functions.

8. How is the module powered?
It operates on 24 V DC supplied through the Ovation rack.

9. Can it be replaced without shutting down the system?
In many configurations, it supports hot-swap capability depending on system design.

10. What are its physical dimensions and weight?
Approx. 120 × 30 × 95 mm with a weight around 0.55 kg.
