The Ovation 5X00481G04 Control Module is a core processing unit within the Emerson Ovation Distributed Control System (DCS), designed to deliver reliable and deterministic control for industrial automation applications. This module provides advanced control capabilities, robust logic execution, and seamless integration with Ovation I/O and communication networks.
Built for environments where precision, uptime, and scalable architecture matter, the 5X00481G04 supports complex control strategies and plays a central role in the automation of power, process, and utility systems.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | Emerson Ovation |
| Model | 5X00481G04 |
| Module Type | Control Module (CPU) |
| Processing Type | Embedded control engine |
| Programming Environment | Ovation system configuration tools |
| Supported Logic | Multi‑tasking structured logic |
| I/O Interface | Backplane communication with I/O modules |
| Network Communication | System bus interfaces |
| Memory | Program and data memory (system dependent) |
| Diagnostics | Built‑in status, fault, and health reporting |
| Power Source | Rack backplane power |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | –40 °C to 70 °C |
| Humidity | 5 % to 95 % non‑condensing |
| Dimensions (HxWxD) | Approx. 125 × 35 × 180 mm |
| Weight | Approx. 0.38 kg |
| Mounting | Rack slot installation |
Typical Industrial Applications
The 5X00481G04 Control Module is widely used where reliable, distributed automation control is essential:
-
Power generation plant operations and regulatory control
-
Process industries including chemical, refining, and utilities
-
Water treatment and wastewater management systems
-
Material handling and infrastructure automation
-
Hybrid control strategies integrating logic, analog, and event operations
Technical FAQs
1. What is the purpose of this control module?
It serves as the main CPU for running control logic and coordinating system I/O within an Ovation DCS.
2. What programming environment does it support?
Configured and programmed through Ovation system tools with structured logic support.
3. How does it communicate with I/O modules?
Via the Ovation rack backplane and system communication bus.
4. Does it support diagnostic reporting?
Yes, it includes built‑in status and fault reporting for easier maintenance.
5. Is it suitable for real‑time control tasks?
Yes, with deterministic execution optimized for industrial logic and control loops.
6. What environmental conditions is it designed for?
Typical industrial ambient conditions up to 55 °C and non‑condensing humidity.
7. Does it require external power?
No; it is powered from the rack backplane.
8. Can it handle large control programs?
Yes, memory and processing are sized to support complex process logic.
9. How is the module mounted?
It installs in a standard Ovation rack slot.
10. What are the approximate dimensions?
Approximately 125 × 35 × 180 mm; about 0.38 kg.
