The Bently Nevada 3500/05-02-01-00-00-00 System Rack is a compact chassis designed for installations that require full 3500 monitoring capability but in a reduced footprint.
This document is written in the style of a hardware-focused engineering brief, emphasizing rack architecture, mechanical behavior, and integration considerations for smaller monitoring panels.
Unlike the larger 19-inch, 14-slot versions, this 12-inch rack provides seven module positions, making it well-suited for applications with limited monitoring channels or cabinet space. Even with its smaller size, it retains the same industrial-grade structural integrity and precise card-guide alignment that define the 3500 platform.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | Bently Nevada 3500/05-02-01-00-00-00 |
| Module Type | System Rack |
| Rack Format | 12-inch compact frame |
| Slot Capacity | 7 module slots |
| Electrical Interface | Integrated backplane for synchronized power and signal distribution |
| Structural Design | Rigid frame with vibration-resistant card guides |
| Typical Use | Space-constrained monitoring panels and distributed protection nodes |
| Installation | Panel or small-cabinet mounting |
| Dimensions | 12-inch rack width (7-slot configuration) |
| Weight | 4.5 kg |
