The Bently Nevada 3500/05-01-03-05-00-01 System Rack is the physical and electrical foundation for assembling a full 3500 machinery protection and condition monitoring system.
This edition is written in the style of a system architecture overview, emphasizing how the rack functions as the central infrastructure through which all monitoring, relay, and communication modules interact.
Engineered around the 19-inch industrial standard, the rack features fourteen module slots arranged along a unified backplane. This backplane establishes controlled electrical pathways for accurate vibration, speed, and process monitoring—critical for safeguarding rotating machinery in demanding industrial environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | Bently Nevada 3500/05-01-03-05-00-01 |
| Module Type | System Rack |
| Rack Format | 19-inch instrumentation standard |
| Slot Count | 14 positions for monitoring, relay, power, and communication modules |
| Electrical Interface | Integrated system backplane for synchronized power and signal routing |
| Mechanical Design | Robust frame with precision module guides for high vibration tolerance |
| Installation | Panel mount or cabinet mount within control enclosures |
| Dimensions | 19-inch rack width (14-slot configuration) |
| Weight | 4.5 kg |
