The Bently Nevada 3500/05-01-03-02-00-01 System Rack is the structural and electrical framework in which a complete 3500 protection system is assembled.
This version is written in a technical integration note style, focusing on how the rack performs as a backbone element in large, multi-channel turbomachinery monitoring installations.
Its 19-inch form factor supports fourteen modules arranged along a unified backplane. This ensures accurate signal routing, consistent power delivery, and mechanically stable seating even in facilities with significant vibration and thermal gradients. The rack is typically positioned in central control cabinets where organized module layout and long-term reliability are essential.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | Bently Nevada 3500/05-01-03-02-00-01 |
| Module Type | System Rack |
| Rack Standard | 19-inch instrumentation frame |
| Slot Capacity | 14 module locations |
| Electrical Backbone | Integrated backplane for synchronized power and signal distribution |
| Mechanical Structure | Reinforced frame with guided module rails |
| Installation Method | Cabinet or panel mounting in control rooms |
| Dimensions | 19-inch rack width (14-slot configuration) |
| Weight | 4.5 kg |
