Introduction
The Bently Nevada 3500/05-01-03-01-00-01 System Rack functions as the central structural frame for the 3500 machinery protection and condition monitoring system.
This document takes the form of a component-level engineering overview, focusing on how the rack operates as the foundation for multi-module assemblies used in high-value rotating equipment applications.
Designed around the standard 19-inch instrumentation format, the rack supports up to fourteen modules—including monitoring cards, relay modules, power supplies, and communication interfaces. Its internal backplane ensures consistent power distribution and signal routing, while the rigid mechanical build maintains module alignment under industrial vibration and thermal cycling.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | Bently Nevada 3500/05-01-03-01-00-01 |
| Module Type | System Rack |
| Rack Standard | 19-inch instrumentation frame |
| Slot Capacity | 14 module positions |
| Backplane Type | Integrated backplane for power and signal distribution |
| Mechanical Design | Rigid industrial frame with precision card guides |
| Installation | Cabinet or panel mount |
| Dimensions | 19-inch rack width (14-slot configuration) |
| Weight | 4.5 kg |
