ABB GV C750 BE101 3BHE009681R0101 IGCT Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB GV C750 BE101 3BHE009681R0101 IGCT Module

Name: ABB GV C750 BE101 3BHE009681R0101 IGCT Module
Brand: ABB PLC
SKU: 971
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:GV C750 BE101 3BHE009681R0101
Product Origin:Sweden
Product Dimensions:250 x 200 x 80 mm
Product Weight:0.45 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB GV C750 BE101 3BHE009681R0101 is an IGCT (Integrated Gate-Commutated Thyristor) module engineered for high-power conversion systems requiring fast, reliable, and thermally stable switching.
This document adopts an engineering review tone, examining the module as a performance component rather than a simple part listing. The GVC750BE101 is widely used in medium- and high-voltage industrial drives, where its switching efficiency and ruggedness directly influence system reliability.

IGCT technology is chosen for applications that exceed the thermal or endurance limits of conventional IGBTs, giving system designers a durable and predictable option for continuous high-load operation.

Technical Specifications

Parameter	Value
Product Model	ABB GV C750 BE101 3BHE009681R0101
Module Type	IGCT Module
Switching Device	Integrated Gate-Commutated Thyristor
Functional Role	High-power switching in drive and converter topologies
Electrical Characteristics	High-current, high-voltage switching capability with low conduction losses
Cooling Method	Cabinet-level forced-air or conduction via heat spreader
Mounting Configuration	Power stack / converter frame installation
Dimensions	250 × 200 × 80 mm (H × W × D)
Weight	0.45 kg

Applications

Medium- and high-voltage industrial drive systems
Power conversion units using IGCT-based switching stages
High-power motor-control platforms in heavy industries
Inverter and converter assemblies for energy or process applications
Replacement module for ABB IGCT-based power-electronic systems

Advantages

IGCT structure delivers exceptionally low conduction losses at high currents
Mechanically robust for long-term operation under thermal cycling
High switching endurance suitable for continuous industrial duty
Tight device behavior reduces stress on surrounding power components
Compatible with ABB gate-drive and converter architectures
Offers predictable switching dynamics beneficial for closed-loop control
Simplifies maintenance due to modular construction
Supports high-efficiency operation in modern power stacks

Technical FAQs

What distinguishes an IGCT module from an IGBT?
IGCTs handle higher current and thermal loads with lower conduction losses, making them suitable for heavy-duty industrial applications.
Does the GV C750 BE101 require a specific gate driver?
Yes, IGCTs must operate with matched ABB gate-drive units to ensure correct turn-on and turn-off behavior.
Can the module be used in multi-level converter architectures?
Yes, it is frequently deployed in high-power multi-level topologies.
Is the module sensitive to installation orientation?
It should be installed according to the converter’s mechanical layout to maintain proper cooling and isolation.
Does it support fast turn-off capability?
IGCTs offer significantly faster turn-off performance than traditional GTOs.
Can it operate in high-vibration environments?
Yes, provided it is mounted securely within the power stack.
Is thermal grease or an interface material required?
Typically yes, to ensure efficient heat transfer to the cooling structure.
Can this module be field-repaired?
No; IGCT modules are replaced as complete units.
Does it include integrated protection features?
Protection is generally handled by the gate-driver and system-level electronics.
Is it suitable for regenerative drive applications?
Yes, when paired with compatible power-stack and control architectures.
