Overview
The Bently Nevada 330130-045-11-05 is a 3300 XL Standard Extension Cable for the 3300 XL 8 mm Proximity Transducer System. It connects a compatible 3300 XL proximity probe to a 3300 XL Proximitor Sensor, preserving the calibrated electrical characteristics required for accurate shaft vibration and shaft position monitoring. This version features an Armored FluidLoc cable and is intended for applications requiring enhanced environmental sealing and mechanical protection.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Standard Extension Cable |
| Manufacturer | Bently Nevada |
| Model | 330130-045-11-05 |
| Product Series | 3300 XL |
| Compatible System | 3300 XL 8 mm Proximity Transducer System |
| Cable Length | 4.5 m (14.8 ft) |
| Cable Construction | Armored FluidLoc® cable |
| Characteristic Impedance | 75 Ω |
| Typical Cable Capacitance | 69.9 pF/m (21.3 pF/ft) |
| Connector Type | Miniature ClickLoc® coaxial connectors |
| Agency Approval | 05 – Multiple approvals (CSA, ATEX, IECEx) |
| Country of Origin | USA |
