Introduction
The Honeywell 8C-TAOXA1 (51307135-175) Analog Output Connection Module provides a stable and organized interface for routing analog output signals from the control system to field devices. It is designed to maintain signal integrity, simplify wiring, and ensure dependable operation in complex industrial environments.
Technical Specifications
| Parameter | Description |
|---|
| Module Type | Analog Output Connection Module |
| Model | 8C-TAOXA1 |
| Part Number | 51307135-175 |
| Dimensions | 220 × 120 × 152.4 mm (H × W × D) |
| Weight | 0.3 kg |
| Primary Function | Organized termination and routing of analog output signals |
| System Compatibility | Honeywell automation and DCS platforms |
Applications
• Structured distribution of analog output signals to field instrumentation
• Integration of control valves, actuators, and drives within Honeywell process systems
• Expansion of output wiring capacity in existing control cabinets
• Optimization of wiring layouts in large-scale automation projects
• Support for stable analog output transmission in industrial facilities
Advantages
• Clean and reliable wiring interface for analog output channels
• Improves system organization and reduces wiring errors
• Ensures stable and low-noise signal delivery to field devices
• Compact layout for efficient control panel integration
• Long-term durability suited for heavy-duty industrial environments
Technical FAQs
-
What is the primary role of the 8C-TAOXA1 module?
It provides a structured connection interface for analog output signals.
-
Does it include active electronics?
It is primarily a connection and termination module.
-
How is it installed within the system?
Mounted in the control cabinet and linked to the output module and field wiring.
-
Is it compatible with Honeywell Experion systems?
Yes, it is fully compatible.
-
Can it be used with different types of actuators?
It supports any field actuator or device driven by analog output signals.
-
Does it require external power?
No external power is needed for termination modules.
-
What wiring types does it support?
Standard industrial signal wiring suitable for analog outputs.
-
Does it include channel isolation?
Isolation depends on the upstream analog output module.
-
Is maintenance required?
Minimal, limited to routine inspection of wiring connections.
-
In what industries is it commonly used?
Oil & gas, refining, chemical plants, and power generation facilities.
