Introduction
The Yokogawa AAI143-H00/A4S00 Analog Input Module is engineered for high-precision signal measurement across complex industrial processes. With its stable performance, noise-resistant design, and strong integration capabilities, it supports reliable data acquisition essential for modern control systems.
Technical Specifications
| Parameter | Description |
|---|
| Module Type | Analog Input Module |
| Model | AAI143-H00/A4S00 |
| Dimensions | 107.5 × 32.8 × 130 mm (H × W × D) |
| Weight | 0.3 kg |
| Function | High-accuracy analog signal input |
| Mounting | Installs into standard Yokogawa I/O base or rack |
Applications
• Acquisition of analog signals from field transmitters
• Continuous monitoring in chemical and process industries
• Power plant and utility system instrumentation
• DCS input expansion for large-scale automation networks
• Precision measurement loops in advanced control systems
• Data collection for refining, petrochemical, and energy sectors
Advantages
• Reliable and stable analog measurement performance
• Robust resistance to industrial electromagnetic noise
• Compact module size enabling dense panel installations
• Long-term durability with minimal maintenance needs
• Seamless integration with Yokogawa CENTUM architectures
• Suitable for a wide range of process input requirements
Technical FAQs
-
What types of input signals does the AAI143-H00/A4S00 support?
Compatible with standard industrial analog input ranges depending on configuration.
-
Does this model include HART capability?
H00 variants typically do not support HART unless extended function codes specify otherwise.
-
How is the module powered?
Power is supplied through the system backplane.
-
Is hot-swapping supported?
Depends on the rack and overall system architecture.
-
How many measurement channels are included?
Channel count varies across the AAI143 series versions.
-
Is calibration required during operation?
Delivered factory-calibrated; recalibration intervals depend on plant standards.
-
Is it compatible with Yokogawa CENTUM systems?
Yes, fully compatible and optimized for Yokogawa DCS environments.
-
Can it operate under high-noise industrial conditions?
Yes, designed with strong noise immunity for harsh environments.
-
Does it provide diagnostic information?
Diagnostics are accessible through the control system interface.
-
Can it interface with third-party control systems?
Possible via interface modules, though optimized for Yokogawa platforms.
