ABB 5SDD2545L0001 3BHL000986P3012 IGCT Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB 5SDD2545L0001 3BHL000986P3012 IGCT Module

Name: ABB 5SDD2545L0001 3BHL000986P3012 IGCT Module
Brand: ABB PLC
SKU: 824
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:SDD2545L0001 3BHL000986P3012
Product Origin:Sweden
Product Dimensions:32 x 127 x 127 mm
Product Weight:0.2 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB 5SDD2545L0001 / 3BHL000986P3012 IGCT module is a high-reliability power semiconductor designed for demanding industrial power conversion. As part of ABB’s Integrated Gate-Commutated Thyristor lineup, this device blends low conduction losses, fast switching behavior, and excellent ruggedness against electrical and thermal cycling. It is widely deployed in medium-voltage drives, large inverters, and power quality solutions where stable and efficient switching performance is critical.

Technical Specifications

Parameter	Details
Manufacturer	ABB
Model	5SDD2545L0001
Ordering Number	3BHL000986P3012
Module Type	IGCT Module
Function	High-power switching semiconductor
Application Range	Medium-voltage drives, high-power converters, industrial power systems
Dimensions	32 × 127 × 127 mm (H × W × D)
Weight	0.2 kg
Thermal Endurance	High resistance to thermal cycling
Electrical Characteristics	Low on-state losses, rapid turn-off capability
Mechanical Structure	Disc-type thyristor with integrated gate commutation unit

Applications

High-power inverter and converter systems
Medium-voltage drive platforms
Power quality systems such as SVCs and STATCOM units
Industrial power distribution switching
Energy, metals, mining, and heavy-process equipment

Advantages

High switching efficiency for reduced system energy loss and improved performance.
Robust thermal capability allowing stable operation under cyclic heating and heavy load.
Integrated gate-commutation design delivering precise control and faster turn-off compared with classic GTOs.
Low conduction losses contributing to cooler operation and longer component life.
Rugged mechanical construction ensuring reliability in vibration- and stress-prone environments.

Technical FAQs (10)

Is this IGCT suitable for medium-voltage drive systems?
Yes, it is widely used in MV drive architectures.
How does an IGCT differ from a GTO?
IGCTs integrate their gate driver and achieve significantly faster turn-off performance.
Does it require specialized cooling?
Yes, most applications use heatsinks or liquid cooling systems.
Can the module be used in inverter applications?
Absolutely—its characteristics suit high-power inverter topologies.
Does the device require ESD protection?
Yes, ESD precautions are recommended when handling.
Is switching frequency high?
IGCTs switch faster than GTOs but generally at lower frequencies than IGBTs.
Is field replacement difficult?
Replacement is straightforward with proper mounting force and insulation procedures.
Is the gate unit integrated into the module?
Yes, integration is a defining feature of IGCT technology.
How long is its operational lifespan?
These modules are engineered for long service life in industrial duty cycles.
Can it be used in power quality systems?
Yes, it is commonly applied in SVC and similar compensation equipment.
