High-Performance Optical Communication Interface for Industrial Automation
The ABB UF D128 A101 3BHE012049R0101 Optical Module is a robust industrial-grade fiber optic communication unit designed for high-speed, interference-free data transmission within ABB automation and power control systems. Engineered for precision signal conversion and long-distance optical communication, it ensures stable and reliable connectivity between distributed control components in complex industrial environments.
Built on ABB’s advanced optical interface architecture, this module enhances system communication integrity, reduces electromagnetic interference issues, and supports real-time data exchange in mission-critical automation applications.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | ABB |
| Model | UF D128 A101 |
| Part Number | 3BHE012049R0101 |
| Product Type | Optical Module / Fiber Optic Communication Board |
| Function | Optical Signal Transmission & System Interface |
| System Platform | ABB AC 800PEC / Industrial Control Systems |
| Communication Type | Fiber Optic (POF / HCS supported system-dependent) |
| Data Transmission | High-speed optical communication |
| Installation Type | Internal Control Rack / Module Slot |
| Operating Temperature | 0°C to +60°C (typical industrial range) |
| Storage Temperature | -20°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Cooling Method | Passive cooling design |
| Construction | Industrial-grade PCB with optical transceiver components |
| Dimensions | Compact module form factor (control cabinet compatible) |
| Weight | Approx. 0.5 kg – 1.9 kg (variant dependent) |
Industrial Applications
The ABB UF D128 A101 Optical Module is widely deployed in high-demand industrial environments where stable optical communication is essential:
-
Power generation control systems
-
ABB AC 800PEC power electronics platforms
-
Industrial drive and inverter systems
-
Distributed control systems (DCS)
-
Renewable energy conversion systems
-
Heavy industrial automation lines
-
High-voltage electrical control environments
-
Process control and monitoring systems
Its fiber optic architecture ensures strong resistance to electromagnetic interference, making it ideal for electrically noisy industrial zones.
Key Advantages
High-Speed Optical Communication
Enables fast and stable data transmission between control modules with minimal latency.
EMI-Free Signal Integrity
Fiber optic technology eliminates electromagnetic interference, ensuring clean and accurate signal transfer.
Industrial Reliability Design
Built to withstand harsh operating conditions including vibration, temperature fluctuations, and electrical stress.
ABB System Integration
Fully compatible with ABB AC 800PEC and related industrial automation architectures for seamless deployment.
Compact Modular Structure
Designed for easy installation within control racks and industrial cabinets.
Enhanced System Stability
Improves overall automation reliability by ensuring consistent communication across system components.
Technical FAQs
1. What is the main function of this optical module?
It provides high-speed fiber optic communication between ABB control system components.
2. Where is it commonly used?
It is widely used in ABB AC 800PEC systems, power plants, and industrial automation environments.
3. Why is fiber optic communication important in industrial systems?
It ensures immunity to electromagnetic interference and supports long-distance stable data transmission.
4. Is this module compatible with ABB systems?
Yes, it is specifically designed for ABB industrial automation platforms.
5. What type of signal does it handle?
It handles optical digital signals for system communication and control coordination.
6. Can it operate in harsh environments?
Yes, it is engineered for industrial-grade durability and reliability.
7. What is its operating temperature range?
Typically between 0°C and +60°C depending on system configuration.
8. Does it require active cooling?
No, it uses a passive cooling design for stable operation.
9. What industries use this module?
Energy, manufacturing, heavy industry, and automation sectors.
10. What makes ABB optical modules valuable?
They provide stable, high-speed, and interference-resistant communication for critical automation systems.
