Stable and Efficient Field Wiring Interface for Industrial Control Systems
The Yokogawa ATI3S-00 Pressure Clamp Terminal Block is designed to deliver secure and maintenance-friendly wiring connections for industrial automation environments. Built for integration with Yokogawa DCS and isolated I/O architectures, this terminal block ensures consistent signal transmission between field devices and control modules while simplifying installation in complex control cabinets.
Its pressure clamp technology provides strong, vibration-resistant contact force without the need for repeated tightening, helping maintain long-term wiring stability. The ATI3S-00 is widely used in process industries where dependable signal integrity and structured wiring layouts are essential for safe and efficient operation.
Technical Specifications
| Parameter | Specification |
|---|
| Model | ATI3S-00 |
| Product Type | Pressure Clamp Terminal Block |
| Manufacturer | Yokogawa |
| System Compatibility | CENTUM VP / Isolated I/O Modules |
| Supported Modules | AAI135, AAI835, AAP135 |
| Connection Type | Spring Pressure Clamp |
| Channel Capacity | Up to 8 channels (application dependent) |
| Signal Type | Analog / Pulse Field Signals |
| Surge Protection | Available in selected configurations |
| Mounting Method | DIN Rail / Control Cabinet Mount |
| Operating Temperature | -20°C to +70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Insulation Design | Industrial-grade isolation structure |
| Dimensions | Approx. 127 × 229 × 178 mm |
| Weight | Approx. 0.3 kg |
Typical Application Areas
-
Distributed control systems (DCS)
-
Process automation industries
-
Oil and gas production facilities
-
Chemical and petrochemical plants
-
Power generation control systems
-
Water treatment and utilities
-
Industrial instrumentation panels
-
Field signal integration systems
Key Advantages
Secure Pressure Clamp Technology
The spring-based clamping system ensures consistent electrical contact, reducing the risk of loose wiring under vibration or thermal cycling.
Simplified Installation Process
Tool-free wiring reduces installation time and improves efficiency during system commissioning and maintenance.
High Reliability in Industrial Environments
Designed for long-term operation, the terminal block maintains stable performance under harsh industrial conditions.
Optimized System Integration
Fully compatible with Yokogawa control systems, supporting smooth integration with analog and pulse I/O modules.
Compact Cabinet Efficiency
Its space-saving design allows high-density wiring layouts, improving control cabinet organization.
Improved Signal Stability
Low-resistance contact design helps maintain accurate and stable signal transmission across automation networks.
Technical FAQs
1. What is the primary function of the ATI3S-00?
It provides a secure interface between field wiring and Yokogawa control/I-O modules.
2. Which systems support this terminal block?
It is mainly used in Yokogawa CENTUM VP and related DCS platforms.
3. What type of connection method is used?
It uses a spring pressure clamp mechanism for secure wiring.
4. Which modules are compatible?
It supports modules such as AAI135, AAI835, and AAP135.
5. How many channels does it support?
It typically supports up to 8 channels depending on system configuration.
6. Is surge protection available?
Yes, certain configurations include surge absorption protection for system stability.
7. What is the operating temperature range?
It operates reliably between -20°C and +70°C.
8. What mounting method is used?
It supports DIN rail or control cabinet mounting.
9. What is the approximate weight?
Around 0.3 kg.
10. What are the physical dimensions?
Approximately 127 × 229 × 178 mm.
