Reliable Fieldbus Wiring Interface for Stable Industrial Automation
The Yokogawa ATF9S-00 Pressure Clamp Terminal Block is engineered to deliver secure, low-maintenance wiring connections for Foundation Fieldbus-based industrial control systems. Designed for Yokogawa FIO architectures, this terminal block ensures stable signal distribution between field devices and control modules while reducing installation complexity in high-density control cabinets.
Built with a spring pressure clamp mechanism, the ATF9S-00 provides consistent contact force, improving long-term wiring stability even in vibration-prone industrial environments. Its compact footprint and structured channel layout make it a practical solution for modern process automation systems requiring dependable connectivity and efficient panel design.
Technical Specifications
| Parameter | Specification |
|---|
| Model | ATF9S-00 |
| Product Type | Pressure Clamp Terminal Block |
| Manufacturer | Yokogawa |
| System Compatibility | Yokogawa FIO / CENTUM VP |
| Fieldbus Type | Foundation Fieldbus |
| Channel Configuration | 4 Ports (CH1–CH4) |
| Connection Method | Spring Pressure Clamp |
| Compatible Module | ALF111 |
| Mounting Type | DIN Rail / FIO Base Mount |
| Operating Temperature | -20°C to +60°C |
| Environmental Rating | Industrial Grade (ISA G3) |
| Signal Application | Field Device Wiring Interface |
| Dimensions | Approx. 112 × 35.2 × 32.6 mm |
| Weight | Approx. 0.1 kg |
Typical Use Cases
-
Foundation Fieldbus H1 segment wiring
-
Process automation systems
-
Oil and gas control networks
-
Chemical and petrochemical plants
-
Power generation instrumentation
-
Control and marshalling cabinets
-
Industrial signal termination system
Key Advantages
Stable Pressure Clamp Connection
The spring-loaded mechanism ensures consistent terminal pressure, reducing loose wiring risks and improving long-term reliability.
Compact High-Density Design
Its small form factor allows efficient use of cabinet space, especially in systems with dense I/O configurations.
Reduced Maintenance Effort
Tool-free wiring structure minimizes maintenance time and simplifies field troubleshooting tasks.
Strong Fieldbus Compatibility
Optimized for Yokogawa Foundation Fieldbus systems, ensuring smooth integration with ALF111 communication modules.
Industrial Durability
Designed for continuous industrial operation, maintaining stable electrical performance under demanding conditions.
Efficient System Expansion
Supports modular system scaling without requiring major rewiring or cabinet redesign.
Technical FAQs
1. What is the main function of the ATF9S-00?
It provides a secure interface for connecting field wiring to Yokogawa Fieldbus control systems.
2. How many connection points does it support?
The module supports 4 Fieldbus channels (CH1–CH4).
3. Which systems is it compatible with?
It is designed for Yokogawa FIO and CENTUM VP systems.
4. What type of wiring mechanism is used?
It uses a spring pressure clamp connection system.
5. Which communication module is it paired with?
It is typically used with the ALF111 Fieldbus communication module.
6. What is the installation method?
It supports DIN rail or FIO base mounting in control cabinets.
7. Is it suitable for vibration-prone environments?
Yes, the pressure clamp design improves connection stability in such conditions.
8. What is the operating temperature range?
It operates between -20°C and +60°C.
9. What are the physical dimensions?
Approximately 112 × 35.2 × 32.6 mm.
10. What is the weight of the unit?
Approximately 0.1 kg.
