Flexible Interface Solution for Advanced Industrial Wiring Systems
The Yokogawa ATD5T-00 Adapter Terminal Block is designed to provide efficient and organized signal interfacing between field devices and Yokogawa automation systems. Developed for demanding industrial environments, this adapter terminal block simplifies field wiring integration while improving installation reliability and long-term operational stability.
With its high-density connection structure and industrial-grade construction, the ATD5T-00 helps optimize cabinet organization and supports secure signal transmission in critical control applications. Its compact design and dependable connectivity make it a preferred solution for process automation projects requiring stable and maintenance-friendly wiring architecture.
The module is widely deployed in Yokogawa CENTUM VP systems and other industrial control platforms where operational continuity and efficient system integration are essential.
Product Specifications Overview
| Technical Item | Specification |
|---|
| Model Number | ATD5T-00 |
| Product Type | Adapter Terminal Block |
| Manufacturer | Yokogawa |
| Connection Capacity | 32 Points |
| Interface Type | KS Cable Interface |
| Mounting Method | DIN Rail / Panel Mount |
| Compatible Systems | Yokogawa CENTUM VP |
| Signal Compatibility | Multi-Signal Interface Support |
| Wiring Structure | High-Density Terminal Design |
| Operating Temperature | -20°C to +60°C |
| Humidity Range | 5% to 95% Non-Condensing |
| Industrial Protection | EMC-Compatible Design |
| Material Construction | Industrial Plastic and Metal Components |
| Dimensions | Approx. 144 × 144 × 185 mm |
| Weight | Approx. 0.5 kg |
| Country of Origin | Japan |
Typical Industry Applications
-
Distributed control systems (DCS)
-
Process automation facilities
-
Oil and gas operations
-
Chemical processing plants
-
Power generation systems
-
Industrial manufacturing lines
-
Instrumentation signal management
-
High-density control cabinets
Key Product Advantages
Simplified Field Wiring
The adapter terminal structure allows fast and organized connection between field devices and control modules, reducing installation complexity.
High-Density Connection Capability
With support for 32 connection points, the ATD5T-00 helps maximize cabinet efficiency in large-scale automation systems.
Industrial-Grade Reliability
Built for demanding environments, the terminal block maintains stable operation during long-term industrial use.
Optimized System Integration
The module integrates smoothly with Yokogawa CENTUM VP systems, supporting efficient commissioning and maintenance procedures.
Compact and Durable Design
Its robust construction and space-saving layout make it suitable for modern industrial control panels with limited installation space.
Improved Operational Stability
Reliable signal transmission helps minimize wiring interruptions and enhances overall automation system performance.
Technical FAQs
1. What is the primary function of the ATD5T-00?
The ATD5T-00 is used to connect field wiring to Yokogawa I/O modules in industrial automation systems.
2. How many connection points does the module support?
The terminal block supports up to 32 connection points.
3. Which Yokogawa systems are compatible with this module?
It is commonly used with Yokogawa CENTUM VP distributed control systems.
4. What type of interface does the module use?
The module uses a KS cable interface for signal connectivity.
5. Is the ATD5T-00 suitable for industrial environments?
Yes, it is designed for continuous industrial automation applications.
6. What mounting methods are supported?
The terminal block supports DIN rail and panel mounting installations.
7. Can the module support multiple signal types?
Yes, it is designed to support various industrial signal connections.
8. Does the module help reduce cabinet wiring complexity?
Yes, its organized terminal structure simplifies field wiring management.
9. What are the dimensions of the ATD5T-00?
The approximate dimensions are 144 × 144 × 185 mm.
10. What is the approximate product weight?
The unit weighs approximately 0.5 kg.
