Reliable Digital Output Wiring for Industrial Automation
The Yokogawa ATD5S-00 Pressure Clamp Terminal Block is developed to provide secure and stable field wiring connections for digital output applications in advanced industrial automation systems. Designed for high-performance control environments, this terminal block delivers dependable electrical connectivity, simplified maintenance, and long-term operational stability.
Its pressure clamp connection structure improves wiring efficiency while reducing the risk of loose connections caused by vibration or continuous operation. The ATD5S-00 is widely used within Yokogawa CENTUM VP systems, offering excellent compatibility with digital output modules in process control applications.
Engineered with industrial durability in mind, the module supports reliable signal transmission in critical production facilities where stable system communication and minimized downtime are essential.
Technical Specifications
| Item | Specification |
|---|
| Model Number | ATD5S-00 |
| Product Type | Pressure Clamp Terminal Block |
| Manufacturer | Yokogawa |
| Application | Digital Output Wiring |
| Connection Method | Pressure Clamp Terminal |
| Compatible Systems | Yokogawa CENTUM VP |
| Compatible Module | ADV551 |
| Channel Capacity | 32 Channels |
| Surge Protection | Integrated Surge Absorber |
| Mounting Method | DIN Rail / Panel Mount |
| Electrical Isolation | Supported |
| Operating Temperature | -20°C to +60°C |
| Relative Humidity | 5% to 95% RH Non-Condensing |
| EMC Compliance | EN61000-6-2 |
| Dimensions | Approx. 114 × 32 × 61 mm |
| Weight | Approx. 0.3 kg |
| Country of Origin | Japan |
Common Industries and Systems
-
Distributed control systems (DCS)
-
Process automation plants
-
Petrochemical facilities
-
Power generation systems
-
Oil and gas processing
-
Water treatment automation
-
Industrial manufacturing lines
-
Field instrumentation control panels
Performance Advantages
Secure Pressure Clamp Design
The spring pressure mechanism maintains reliable conductor contact, helping reduce maintenance issues caused by loose wiring.
Improved Wiring Efficiency
Compared with traditional screw terminals, the ATD5S-00 enables faster installation and easier maintenance procedures.
Stable Industrial Operation
Built for continuous industrial usage, the terminal block supports dependable performance in harsh operating environments.
Surge Protection Capability
Integrated surge absorption helps protect connected I/O modules from unexpected electrical disturbances.
Compact Cabinet Integration
Its slim-profile structure allows efficient installation inside high-density control cabinets.
Optimized System Compatibility
The terminal block is specifically engineered for seamless integration with Yokogawa CENTUM VP digital output architectures.
Technical FAQs
1. What is the main purpose of the ATD5S-00?
The ATD5S-00 is used to connect field devices to digital output modules in industrial automation systems.
2. Which Yokogawa system supports this terminal block?
It is commonly used within Yokogawa CENTUM VP distributed control systems.
3. What type of connection does the module use?
The module uses a pressure clamp terminal connection mechanism.
4. How many channels are supported?
The ATD5S-00 supports 32-channel digital output wiring.
5. Is surge protection included?
Yes, the terminal block includes surge absorption functionality for improved system protection.
6. Which I/O module is commonly compatible?
The terminal block is compatible with Yokogawa ADV551 modules.
7. Can the module operate in industrial environments with vibration?
Yes, the pressure clamp structure is designed for vibration-resistant industrial applications.
8. What mounting options are available?
The unit supports DIN rail and panel mounting installation methods.
9. What is the operating temperature range?
The recommended operating temperature is between -20°C and +60°C.
10. What are the dimensions and weight?
The approximate dimensions are 114 × 32 × 61 mm, with a weight of around 0.3 kg.
