Yokogawa AVR10D-Q22021 Duplex V-Net Router

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Yokogawa AVR10D-Q22021 Duplex V-Net Router

Name: Yokogawa AVR10D-Q22021 Duplex V-Net Router
Brand: Yokogawa Electric
SKU: 8155
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:AVR10D-Q22021
Product Origin:Japan
Product Dimensions:150 × 440 × 170 mm
Product Weight:5kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Product Introduction

The Yokogawa AVR10D-Q22021 Duplex V-Net Router is a high-availability network communication module designed for Yokogawa CENTUM Distributed Control Systems (DCS). It enables seamless data exchange between Vnet/IP and V net domains, ensuring stable, deterministic communication across complex industrial automation architectures.

Built with a duplexed (redundant) design philosophy, this router enhances system reliability by maintaining communication continuity even in the event of a network path or module failure. It is widely used in large-scale process industries where uninterrupted control data flow is essential for safe and efficient operations.

Technical Specifications

Parameter	Specification
Model	AVR10D-Q22021
Module Type	Duplex V-Net Router
System Compatibility	Yokogawa CENTUM VP / CENTUM CS
Network Types	Vnet/IP ↔ V net
Vnet/IP Speed	100 Mbps, full duplex
V net Speed	10 Mbps (dual-redundant supported)
Interface	RJ45 (Vnet/IP), BNC (V net)
Communication Protocol	Yokogawa proprietary control communication
Redundancy	Duplex communication modules + dual power supply
Power Supply	100–120 V AC / 220–240 V AC (variant dependent)
Power Consumption	~80–110 VA
Mounting Type	19-inch rack-mounted unit
Operating Temperature	0°C to +55°C
Storage Temperature	-20°C to +70°C
Dimensions (H×W×D)	~150 × 440 × 170 mm
Weight	Approx. 5 kg
System Function	Inter-domain control communication router

Industrial Applications

The AVR10D-Q22021 is used in mission-critical automation environments where multiple control domains must communicate reliably:

Large-scale oil & gas production facilities
Petrochemical and refinery distributed control systems
Power generation and turbine control networks
Multi-site industrial plant integration
CENTUM-based hierarchical control architectures

It is especially valuable in systems requiring secure and stable communication between geographically or logically separated control domains.

Key Advantages

Fully Duplexed Architecture: Dual communication modules ensure uninterrupted operation
High-Speed Vnet/IP Connectivity: Supports 100 Mbps full-duplex communication for modern control systems
Legacy V net Compatibility: Maintains support for older CENTUM infrastructures
Redundant Design Philosophy: Dual power and communication paths improve system availability
Seamless Domain Integration: Enables communication between multiple Vnet/IP domains and V net systems
Industrial Reliability: Designed for continuous 24/7 operation in harsh environments

Technical FAQs

1. What is the main function of the AVR10D-Q22021?
It connects and routes control data between Vnet/IP and V net domains in Yokogawa DCS systems.

2. What does “duplex” mean in this model?
It refers to redundant communication modules and power supply for high system availability.

3. What communication speeds does it support?
100 Mbps for Vnet/IP and 10 Mbps for V net networks.

4. What systems is it compatible with?
Yokogawa CENTUM VP, CENTUM CS 3000, and related architectures.

5. What happens if one communication path fails?
The redundant path automatically maintains communication continuity.

6. What type of connectors are used?
RJ45 for Vnet/IP and BNC connectors for V net.

7. Is it suitable for modern Ethernet networks?
It integrates Vnet/IP over industrial Ethernet while maintaining legacy compatibility.

8. What is the typical power requirement?
100–240 V AC depending on configuration variant.

9. How is it installed?
It is mounted in a standard 19-inch industrial control rack.

10. Why is it important in DCS systems?
Because it ensures reliable inter-domain communication across complex distributed control architectures.
