Name: Yokogawa AAP135‑S00 / 13S00 Analog Pulse Input Module
Brand: Yokogawa Electric
SKU: 753
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Yokogawa Electric
Item No.:AAP135‑S00 / 13S00
Product Origin:Japan
Product Dimensions:105 mm × 90 mm × 40 mm
Product Weight:0.35kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Yokogawa AAP135‑S00 / 13S00 is a versatile analog pulse input module designed for integration into Yokogawa DCS and PLC systems. It is optimized for capturing pulse signals from field devices such as flow meters, encoders, and other digital pulse sources while maintaining high accuracy and reliability. This module combines fast response times, noise immunity, and robust galvanic isolation, making it ideal for industrial process monitoring, batch and continuous control, and automated measurement applications across chemical, water treatment, energy, and manufacturing industries.

Technical Specifications

Parameter	Details
Module Type	Analog Pulse Input Module
Input Channels	8 pulse input channels
Supported Signal Types	Dry contact, NPN/PNP open collector, voltage pulse (5–24 V DC)
Input Frequency Range	0–10 kHz typical
Minimum Pulse Width	50 μs
Counting Resolution	32-bit counters per channel
Isolation	Full galvanic isolation between inputs and system; withstand voltage 1500 V AC for 1 minute
Response Time	<100 μs per pulse
Power Supply / Consumption	Powered via standard I/O module nest; low current draw
Mounting / Compatibility	Standard Yokogawa analog/digital I/O rack or module nest
Dimensions (H × W × D)	105 mm × 90 mm × 40 mm
Weight	Approx. 0.35 kg

Applications

Counting pulses from flow meters, energy meters, and encoders.
High-speed digital signal acquisition for process control.
Integration into DCS/PLC systems for batch or continuous processes.
Industrial automation systems requiring precise pulse measurements.
OEM panels and instrumentation requiring multi-channel pulse input capabilities.

Advantages

High-speed pulse acquisition — reliable up to 10 kHz.
Multi-signal support — accepts dry contact, NPN/PNP, and voltage pulses.
High-resolution counters — 32-bit per channel allows accurate long-term counting.
Robust isolation — protects system from electrical interference and ground loops.
Fast response — <100 μs per pulse ensures precise real-time control.
Compact and modular — fits standard Yokogawa I/O racks for flexible installation.

Technical FAQs (10)

Q: How many pulse input channels does the module have?
A: 8 channels.
Q: What pulse signal types are supported?
A: Dry contact, NPN/PNP open collector, and voltage pulses (5–24 V DC).
Q: What is the maximum input frequency?
A: Up to 10 kHz typical.
Q: What is the minimum pulse width the module can detect?
A: 50 μs.
Q: What is the counting resolution per channel?
A: 32-bit counters.
Q: Are the pulse inputs isolated from the system?
A: Yes, full galvanic isolation with 1500 V AC withstand voltage for 1 minute.
Q: What is the response time per pulse?
A: Less than 100 μs.
Q: What are the module dimensions and weight?
A: 105 mm × 90 mm × 40 mm; weight approx. 0.35 kg.
Q: Can the module be installed in standard Yokogawa I/O racks?
A: Yes, it is compatible with standard analog/digital module nests.
Q: What applications are ideal for this module?
A: Flow meter pulse counting, encoder monitoring, process automation, batch and continuous control, and industrial automation requiring multi-channel pulse inputs.
