Introduction
The Yokogawa AAM11B is a versatile analog input module designed for industrial control systems, delivering precise current or voltage signal acquisition for process automation and monitoring. Whether you’re reading 4–20 mA transmitter outputs or 0–10 V signals from field sensors, this module converts those analog inputs into stable digital data for the controller. Built to integrate into Yokogawa DCS racks (e.g. CENTUM systems), the AAM11B offers flexibility, accuracy and robust isolation — ideal for chemical plants, water treatment systems, energy monitoring, and other industrial environments requiring dependable analog measurement.
Technical Specifications
| Parameter | Details |
|---|---|
| Module Type | Current/Voltage Analog Input Module |
| Input Signal Types | DC Current (0–20 mA), DC Voltage (0–10 V) |
| Input Resistance | Current mode: ~ 250 Ω; Voltage mode: ~ 1 MΩ (power on) |
| Allowable Input Range | Voltage: –10 V to +30 V; Current: up to 40 mA DC |
| Auxiliary Transmitter Power Supply | 25.0–25.5 V DC (when powering two‑wire transmitters) |
| Accuracy (at nominal conditions) | Voltage input: ±4 mV; Current input: ±16 µA |
| Temperature Drift | Per 10 °C change: Voltage: ±4 mV + ±0.15% of reading; Current: ±32 µA |
| Data Update Interval | 50 ms |
| Isolation / Withstand Voltage | Input signals galvanically isolated from system; withstands 1500 V AC for 1 min |
| Mounting / Rack Compatibility | Fits I/O module nest / rack for Yokogawa control systems |
| Power Consumption | ≤ 300 mA @ 5.0 V DC supply |
| Module Dimensions / Form Factor | Designed to slot into standard I/O rack (size per Yokogawa rack standards) |
| Other Notes | Configurable input type (current or voltage) via software; can supply transmitter power when needed |
