ABB CCU-23-S 3AXD50000034658 Frequency Converter Drive Board

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

ABB CCU-23-S 3AXD50000034658 Frequency Converter Drive Board

Name: ABB CCU-23-S 3AXD50000034658 Frequency Converter Drive Board
Brand: ABB PLC
SKU: 717
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:ABB PLC
Item No.:CCU-23-S 3AXD50000034658
Product Origin:Sweden
Product Dimensions:203 x 51 x 279 mm
Product Weight:0.2 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The ABB CCU-23-S is a precision-engineered frequency converter drive board developed to coordinate high-performance motor control tasks. Built around a stable and noise-resistant circuit design, the module manages command execution, internal synchronization, and feedback processing within advanced drive systems. Its profile is optimized for service engineers—easy to install, predictable in behavior, and robust enough for continuous operation in demanding electrical environments.

Technical Specifications

Parameter	Description
Model	CCU-23-S
Part Number	3AXD50000034658
Module Type	Frequency Converter Drive Board
Dimensions	203 × 51 × 279 mm (H × W × D)
Weight	0.2 kg
Functional Scope	Frequency conversion logic, signal regulation, drive synchronization
Design Format	Extended board layout for improved thermal and electrical distribution
System Compatibility	Integrated use within ABB frequency converter platforms

Applications

Variable-speed drives for manufacturing and process automation
High-capacity motor systems requiring accurate response control
OEM equipment integrating ABB converter technology
Industrial retrofit projects upgrading older control hardware
Drive cabinets where dependable, long-duration operational stability is essential

Advantages

Reliable performance in sustained motor-control duty cycles
Well-balanced board layout improving cooling and signal consistency
Predictable operation simplifies troubleshooting and maintenance
Designed for integration across multiple ABB converter families
Strong electrical robustness for industrial noise environments

Technical FAQs

Is the CCU-23-S responsible for generating output frequency directly?
It manages frequency-conversion logic but operates as part of the broader drive system.
Does the board require firmware updates?
Updates, when applicable, are handled through the main converter platform.
Can it be replaced without disturbing other boards?
Yes, provided the system is powered down and proper ESD practices are followed.
What type of connectors are used?
ABB-standardized multi-pin logic and communication interfaces.
Is this board suitable for high-speed motor applications?
Yes, if within the rating of the corresponding ABB converter.
Does it support closed-loop feedback?
It processes feedback signals when the drive configuration includes closed-loop control.
Can the board handle environments with high electrical noise?
It is engineered for industrial EMI conditions when installed correctly.
How should the board be cleaned?
Only dry, low-pressure dust removal—no chemicals or moisture.
Is the CCU-23-S interchangeable with earlier CCU-series boards?
Only with models listed as compatible by ABB system specifications.
Does it require alignment or recalibration?
No, the module is factory-set and works according to drive-side configuration parameters.
