ABB BTDR-01C 3AUA0000094845 MD Control Board

Brand:ABB PLC
Item No.:BTDR-01C 3AUA0000094845
Product Origin:Sweden
Product Dimensions:22 x 124 x 126 mm
Product Weight:0.1 kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0
Points

Send Inquiry
  • Product Details
  • Product Applications
  • Product Advantages
  • Technical FAQs
  • Contact




Introduction

The ABB BTDR-01C MD Control Board is a compact, precision-engineered module developed for motion-drive coordination and signal conditioning within ABB drive platforms. Its architecture emphasizes stable logic processing, accurate signal routing, and dependable communication with higher-level control elements. Designed with a technician-friendly layout, the board supports consistent diagnostic behavior and helps maintain operational reliability in demanding industrial environments.

Technical Specifications

ParameterDescription
ModelBTDR-01C
Part Number3AUA0000094845
Module TypeMD Control Board
Dimensions22 × 124 × 126 mm (H × W × D)
Weight0.1 kg
Control RoleMotion-drive logic, command distribution, status signal routing
StructureSlimline circuit board suitable for dense installation layouts
IntegrationDesigned for compatibility with ABB low-voltage drive systems


Applications

  • Multi-axis motor control systems

  • Drive cabinets requiring compact MD logic boards

  • OEM machinery integrating ABB drive technology

  • Replacement modules for preventive or corrective maintenance

  • High-duty production lines with continuous operational demands


Advantages

  • Slim and lightweight design ideal for tight enclosures

  • Reliable logic processing for motion and drive coordination

  • Designed for long-term endurance in industrial environments

  • Quick installation and replacement, reducing service downtime

  • Consistent interoperability with ABB drive architectures


Technical FAQs

  1. Does the BTDR-01C manage standalone control functions?
    It operates as part of the drive system and does not serve as an independent controller.

  2. Is the board hot-swappable?
    Power must be isolated before removal or installation.

  3. What types of signals does it process?
    Internal drive logic, command routing, and feedback coordination.

  4. Is firmware stored on the board?
    Firmware is typically hosted within the main drive module, not on this board.

  5. Can it be used in retrofitting older ABB drives?
    Only for systems explicitly supported by ABB compatibility specifications.

  6. How is the module connected?
    Via ABB-standard multi-pin board connectors.

  7. Does it require periodic recalibration?
    No, calibration is not part of standard maintenance.

  8. Is it resistant to electromagnetic interference?
    Yes, when installed within ABB-approved cabinet designs.

  9. Can the board operate in high-humidity environments?
    Operation requires compliance with the environmental limits of the host drive.

  10. What maintenance is recommended?
    Occasional dust removal following correct ESD and handling procedures.
