Product Overview
The Woodward 8406‑113 Control Operator Interface is a rugged human‑machine interface (HMI) panel designed for intuitive operator control in industrial power generation, turbine systems, and generator control applications. Engineered to provide clear status visualization and easy command input, this interface enhances real‑time monitoring, system diagnostics, and control execution for operators in demanding environments.
Built with ergonomic design and robust industrial‑grade components, the 8406‑113 delivers dependable performance even under vibration, temperature extremes, and high‑noise electrical conditions. Its intuitive layout reduces operator fatigue and supports fast, accurate control decisions—making it ideal for control rooms, auxiliary systems, and remote control stations.
Technical Specifications
| Parameter | Details |
|---|
| Model | 8406‑113 |
| Brand | Woodward |
| Product Type | Control Operator Interface |
| Display | Integrated status and command display |
| Input Controls | Pushbuttons / rotary switches / keypad (configurable) |
| Communication | Compatible with Woodward control networks |
| Power Supply | Typically 24 V DC (system dependent) |
| Mounting | Panel‑mounted or enclosure interface |
| Environmental Rating | Designed for industrial use |
| Operating Temperature | –20°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions | Approx. 250 × 160 × 60 mm |
| Weight | Approx. 0.9 kg |
Application Scenarios
The Woodward 8406‑113 excels in environments that require operator interaction and clear visualization of control states:
-
Power Generation Control Rooms for generator and turbine status monitoring
-
Industrial Automation Centers managing auxiliary equipment and logic
-
Remote Equipment Enclosures where local operator access is needed
-
Marine Power Systems providing interface for propulsion and electrical control
-
Critical Infrastructure Facilities requiring operator oversight and control
The interface supports interactive commands, status alerts, and system feedback that help operators make informed decisions quickly.
Key Advantages
The 8406‑113 Operator Interface is designed for both usability and resilience:
-
Intuitive Layout enables operators to read system status and respond quickly
-
Robust Construction withstands industrial environmental stress
-
Clear Visual Feedback enhances situational awareness
-
Flexible Configuration supports tailored control schemes
-
Reliable Communication integrates seamlessly with Woodward control hardware
These attributes make it a dependable choice for applications where operator interaction is essential for safe and efficient system operation.
Technical FAQs
1. What is the primary function of this interface?
It provides an operator control panel for system monitoring and manual control actions.
2. What types of controls are typically available?
Pushbuttons, keypad, and status indicators can be configured for command entry and feedback.
3. How is it powered?
It generally uses a 24 V DC supply typical of control system environments.
4. Where can it be mounted?
Panel‑mounted in control cabinets or integrated into equipment enclosures.
5. Is it suitable for harsh environments?
Yes, it is built for industrial exposure including temperature range and vibration.
6. What communications does it support?
It interfaces with Woodward controllers and compatible automation networks.
7. Can it display alarms or system statuses?
Yes, it is designed to visualize alarms, status feedback, and system information.
8. Is touchscreen functionality included?
This model typically uses physical controls; touchscreen versions may exist in other series.
9. Is configuration required?
Yes, customization and parameter setup are done through system configuration tools.
10. What makes it stand out?
Its blend of intuitive operator usability, industrial resilience, and compatibility with Woodward control systems.
