Product Overview
The OVATION 5X00300G01 RTD Input Module is a specialized analog interface module designed for high‑precision temperature measurement in OVATION distributed control systems. It converts resistance signals from RTD temperature sensors into accurate digital data for process control and monitoring. This module is especially valuable in systems where precise thermal data is crucial for safety, efficiency, and process optimization.
Its design ensures compatibility across OVATION installations and simplifies discrete signal integration while supporting high‑density system architectures. The 5X00300G01 is a dependable building block for scalable control solutions in utilities, process plants, and mission‑critical industrial facilities.
Technical Specifications
| Parameter | Details |
|---|
| Model | 5X00300G01 |
| Brand | OVATION |
| Module Type | RTD / Temperature Input Module |
| Input Type | Resistance Temperature Detector (RTD) |
| Supported Sensors | 2‑wire, 3‑wire RTDs |
| Accuracy | ±0.1% (typical) |
| Operating Range | –40°C to +85°C |
| Power Supply | 12–24 V DC |
| Power Consumption | ≤ 2 W |
| Isolation | System and channel isolation for noise immunity |
| Dimensions | Approx. 114 × 65 × 30 mm |
| Weight | Approx. 0.10 kg |
Application Scenarios
The OVATION 5X00300G01 module is ideally suited for systems that depend on accurate temperature data:
-
Power generation plants monitoring turbine and boiler temperatures
-
Petrochemical and refining processes requiring precise thermal measurements
-
Water and wastewater treatment systems tracking thermal variations
-
Industrial furnaces and heat‑dependent process controls
-
Safety‑critical systems where temperature anomalies trigger control actions
Its ability to handle standard RTD inputs makes it useful across a broad range of industrial environments.
Core Advantages
-
Precision Temperature Sensing with high accuracy for process optimization
-
Wide Environmental Range suitable for industrial control cabinets
-
RTD Compatibility supports multiple RTD configurations
-
Noise‑Resistant Design improves measurement reliability
-
Compact and Modular Form Factor fits standard OVATION racks
These strengths make the 5X00300G01 an effective and dependable sensor interface in industrial control architectures.
Technical FAQs
1. What type of sensor input does this module support?
It supports Resistance Temperature Detectors (RTDs), including 2‑wire and 3‑wire configurations.
2. What is typical module accuracy?
Measurement accuracy is commonly ±0.1% under stable conditions.
3. Can it operate in noisy environments?
Yes, built‑in signal isolation reduces electrical noise interference.
4. What temperature range can it measure?
While the module operates in control cabinets from –40°C to +85°C, the actual RTD measurement range depends on the connected sensor.
5. How is the power supplied?
It typically uses a low‑voltage DC supply (12–24 V DC).
6. Can this be used for other sensor types?
It’s optimized specifically for RTD temperature sensors and not general analog inputs.
7. Is channel isolation provided?
Yes, electrical isolation enhances signal integrity.
8. What is the module’s footprint?
It has a compact industrial module size for OVATION racks.
9. Does it require configuration software?
Yes, setup is performed through OVATION engineering tools.
10. What makes this module stand out?
Its combination of precision, durability, and compatibility with industrial RTDs.
