Industrial‑Grade DIN Rail Assembly for Automation Systems
The GE IS230TAISH2C DIN Rail Assembly is a rugged mounting infrastructure component designed specifically for industrial automation I/O architectures. It provides a standardized, reliable platform for securing GE automation modules, power supplies, terminal blocks, and peripheral devices within control cabinets or panel enclosures.
Engineered for easy installation, mechanical stability, and long‑term durability, this DIN rail assembly ensures consistent performance in demanding environments such as manufacturing plants, utilities, and process facilities. It helps organize modular components into a neat, maintainable layout that supports complex control and signaling systems.
Technical Specifications
| Parameter | Specification |
|---|
| Manufacturer | GE Automation & Controls |
| Model | IS230TAISH2C |
| Module Type | DIN Rail Assembly |
| Rail Type | Standard industrial DIN rail (35 mm) |
| Material | High‑strength steel or aluminum alloy |
| Surface Finish | Corrosion‑resistant plated finish |
| Compatibility | GE IS200 / IS230 I/O modules, power supplies, terminal blocks |
| Mounting Type | Panel or enclosure mount |
| Mounting Holes | Pre‑drilled for fast installation |
| Operating Temperature | –20 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | Up to 95 % non‑condensing |
| Dimensions | System dependent (rail length and configuration vary) |
| Weight | Depends on rail length and configuration |
Applications
The IS230TAISH2C DIN Rail Assembly is widely used wherever organized and secure module mounting is required:
-
Industrial control cabinets and panel enclosures
-
Machine automation systems
-
Process control I/O rack assemblies
-
Power distribution and I/O interface sections
-
Retrofits and expansion of existing automation cabinets
Applications
The IS230TAISH2C DIN Rail Assembly is widely used wherever organized and secure module mounting is required:
-
Industrial control cabinets and panel enclosures
-
Machine automation systems
-
Process control I/O rack assemblies
-
Power distribution and I/O interface sections
-
Retrofits and expansion of existing automation cabinets
Technical FAQs
1. What is a DIN rail assembly used for?
It provides a secure, standardized mounting platform for automation modules and related hardware inside control panels.
2. What rail size does this assembly support?
Standard 35 mm industrial DIN rail, compatible with most automation modules and terminal blocks.
3. What materials are used in the rail?
High‑strength steel or aluminum with corrosion‑resistant plating for durability.
4. How is the assembly mounted?
Panel or enclosure mount using pre‑drilled holes for secure installation.
5. What environmental conditions can it withstand?
Typical industrial conditions from –20 °C to +70 °C with high humidity tolerance.
6. Can it support multiple modules?
Yes, rail length and configuration determine how many modules and components can be mounted.
7. Does it support retrofit installations?
Yes, ideal for both new and retrofit automation cabinets.
8. Can power supplies and I/O modules share the same rail?
Yes, it supports mounting of I/O modules, power supplies, and terminal blocks in one organized layout.
9. Does the rail require special tools to install?
Standard hand tools and brackets are typically sufficient for assembly.
10. Is grounding provided on the rail?
Grounding is achieved through panel enclosure binding and proper panel grounding practices.
