Schneider TSXDSZ08T2K Relay Discrete Output Module

ABB CI920N 3BDS014113 Communication Interface for Industrial Automation

Schneider TSXDSZ08T2K Relay Discrete Output Module

Name: Schneider TSXDSZ08T2K Relay Discrete Output Module
Brand: Schneider PLC
SKU: 6375
Availability: InStock
Rating: 5.0 (1 reviews)

Brand:Schneider PLC
Item No.:TSXDSZ08T2K
Product Origin:France
Product Dimensions:55 × 180 × 260 mm
Product Weight:0.18kg
Payment:T/T, Western Union, Credit Card
Goods_stock:15
Shipping Port:Xiamen, China
Lead Time:1-3 Days
Condition:Brand New And Original
Warranty:1 Year
Certificate:COO
Evaluation:

0.0

Points

Send Inquiry

Product Details
Product Applications
Product Advantages
Technical FAQs
Contact

Introduction

The Schneider TSXDSZ08T2K Relay Discrete Output Module is a rugged and versatile I/O module designed for Schneider Electric Modicon TSX and TSX Premium PLC systems. Featuring eight independent relay output channels, it provides reliable discrete switching for industrial automation applications where electrical isolation and load versatility are required. With its robust construction and straightforward integration, this module is ideal for controlling relays, contactors, lamps, and other electromechanical devices in demanding environments.

Technical Specifications

Parameter	Specification
Model	TSXDSZ08T2K
Module Type	Relay Discrete Output Module
Series	Schneider Modicon TSX / TSX Premium
Number of Outputs	8 relay outputs
Output Type	Electromechanical relay contacts
Contact Configuration	Form A (SPST normally open)
Rated Load	2 A @ 250 V AC / 2 A @ 30 V DC per relay
Backplane Interface	Plug‑in connection to PLC bus
Isolation	Channel‑to‑backplane isolation
Indicators	LED status for each output
Response Time	Typical relay operate time ~10 ms
Operating Temp	-10°C to +55°C
Storage Temp	-25°C to +70°C
Mounting	Rack / Backplane slot
Weight	Approx. 0.15 kg
Dimensions	Standard discrete output module form factor

Applications

The TSXDSZ08T2K module is widely used where independent discrete switching of loads is required:

Control of contactors and solenoid valves
Switching industrial lamps and indicators
Actuating alarms and signal circuits
Sequential machine control and conveyors
Interfacing PLC outputs to higher‑power field loads

Its relay outputs provide practical electrical isolation and flexibility for both AC and DC loads, making it suitable for a broad range of automation tasks.

Advantages

Eight Independent Outputs: Eight relay channels give ample switching capacity in a single compact module.
Robust Load Handling: Each relay contact can switch up to 2 A at common industrial voltages, accommodating a variety of loads.
Clear Diagnostics: Individual channel LEDs give fast visual feedback on output operation and status.
Plug‑In Integration: Simple installation into TSX / TSX Premium PLC backplane rails reduces setup time.
Versatile Load Support: Relay contacts provide safe isolation and support a wide range of AC and DC devices.

These attributes make the TSXDSZ08T2K a dependable choice for discrete output control in complex industrial systems.

Technical FAQs

1. How many discrete outputs does this module have?
It has 8 independent relay output channels.

2. What type of output contacts are used?
Form A (SPST) electromechanical relay contacts.

3. What load can each relay switch?
Up to 2 A at 250 V AC or 2 A at 30 V DC.

4. Are status indicators provided?
Yes, each output has an LED indicator.

5. How fast do the relays operate?
Typical operate time is around 10 ms.

6. What isolation is provided?
Channel‑to‑backplane isolation improves signal integrity and safety.

7. How is the module mounted?
It installs in a backplane slot connected to the PLC rail.

8. What environments can it operate in?
Designed for industrial ambient temperatures of approximately -10°C to +55°C.

9. Does it work with both AC and DC loads?
Yes, its relay outputs support switching AC and DC loads within rated limits.

10. What is the module’s weight?
Approximately 0.15 kg
