Product Overview
The Bently Nevada 3500/93‑02‑00‑00‑00 135813‑01 System Display Module is an essential human‑machine interface component of the 3500 Machinery Protection System. It provides operators with visual access to real‑time machine health, alarm status, and diagnostic data directly from the protection system. Designed for industrial control panels, this display module delivers clear status indications and configurable views that help technicians make informed decisions during monitoring, troubleshooting, and maintenance.
The 3500 display family is known for durability, intuitive feedback, and seamless integration with the modular 3500 protective architecture, making this module ideal for critical rotating machinery applications where visibility into system status is essential.
Technical Specifications
| Specification | Details |
|---|
| Model | 3500/93‑02‑00‑00‑00 |
| GE Part Number | 135813‑01 |
| Module Type | System Display Module |
| System Series | Bently Nevada 3500 Machinery Protection System |
| Display Type | Alphanumeric / Status indication panel |
| Indicators | Multi‑segment numeric and status annunciators |
| Interface | Backplane communication with 3500 rack |
| Mounting | Front panel (rack‑mounted) |
| Environmental Rating | Industrial, rack enclosure protection |
| Operating Temperature | 0 °C to +60 °C (typical industrial range) |
| Dimensions | Standard 3500 module form factor |
| Weight | Approx. 0.25 kg |
Typical Applications
The 3500/93‑02 System Display Module is used wherever machine protection information must be clearly visible and accessible:
-
Gas and steam turbine health and protection panels
-
Generator vibration and shaft motion monitoring systems
-
Compressor and pump protection systems
-
Industrial machinery where early fault detection is required
-
Control rooms requiring visual status of 3500 protection channels
This module provides operators with quick insight into machine condition, alarm states, and protection actions.
Technical FAQs
1. What is the primary function of this module?
It displays system status, alarm conditions, and diagnostic information from the 3500 Machinery Protection System.
2. Which systems is it compatible with?
It is compatible with Bently Nevada 3500 series protection racks and modules.
3. What type of display does it use?
Alphanumeric and status annunciation elements optimized for clear industrial feedback.
4. How is it mounted?
Front panel mounting in a 3500 system rack or enclosure.
5. Does it show alarm history?
It displays active alarms and real‑time status; some configurations provide historical context depending on system settings.
6. Is it designed for industrial environments?
Yes, it is engineered for typical industrial temperatures and noise conditions.
7. Can it be used remotely?
Primarily it is a local system interface; remote monitoring is typically done through larger system software integrations.
8. Does it require configuration?
Yes, it is usually configured as part of the 3500 system setup to map status bits to display elements.
9. What protections does it show?
Vibration alarms, speed thresholds, proximity faults, and channel health.
10. Is it hot‑swappable?
Depending on system configuration, module removal may require controlled procedures.
