Product Overview
The GE IS200STTCH2A DIN Rail Mounted Thermocouple Terminal Block is designed to provide precise and reliable thermocouple signal interfacing for GE Mark VI Speedtronic control systems. It facilitates accurate temperature measurement by connecting field thermocouples to the control system while maintaining signal integrity.
Built for industrial and turbine applications, this terminal block combines rugged construction with convenient DIN rail mounting, enabling easy installation, maintenance, and secure connections in high-demand environments.
Technical Specifications
| Parameter | Details |
|---|
| Model | IS200STTCH2A |
| Module Type | DIN Rail Mounted Thermocouple Terminal Block |
| Series | GE Mark VI Speedtronic |
| Input Type | Thermocouple (Type J, K, T, E, N, R, S, B) |
| Channels | 8 Thermocouple inputs per module |
| Accuracy | ±0.25% of reading or better |
| Isolation | Galvanic isolation between channels |
| Operating Temperature | -40°C to 70°C |
| Mounting | DIN rail mounted |
| Dimensions (HxWxD) | Approx. 100 x 35 x 75 mm |
| Weight | Approx. 0.35 kg |
| Indicators | None (passive terminal block) |
Typical Applications
The IS200STTCH2A is ideal for accurate temperature measurement and process monitoring in a variety of industrial and turbine environments:
-
Gas and steam turbine control systems
-
Boiler and heat recovery systems
-
Power generation plants
-
Oil & gas processing and refining
-
Industrial process automation
It ensures accurate thermocouple signal transfer to control systems for reliable temperature monitoring and process regulation.
Technical FAQs
1. How many thermocouple inputs does this block support?
It supports 8 thermocouple inputs per module.
2. What types of thermocouples are compatible?
Type J, K, T, E, N, R, S, and B are supported.
3. Is it electrically isolated?
Yes, it provides galvanic isolation between channels.
4. What is the operating temperature range?
-40°C to 70°C.
5. How is it mounted?
It is DIN rail mounted for easy installation.
6. Does it provide LED or status indicators?
No, this is a passive terminal block.
7. What industries commonly use this block?
Power generation, industrial automation, oil & gas, and turbine control.
8. Can it be replaced during system operation?
Yes, the DIN rail design allows safe and convenient replacement.
9. What is its role in system monitoring?
It provides a reliable interface for thermocouple signals to the control system.
10. Is it compatible with Mark VI Speedtronic modules?
Yes, it integrates fully within the Mark VI system.
