Product Overview
The GE IS200STAOH2A Simplex Analog Output Terminal Board is designed to provide precise and reliable analog output signals within the Mark VI Speedtronic control system. It serves as the interface between the control system and field devices such as actuators, valves, and sensors, ensuring accurate and stable signal delivery for critical industrial and turbine applications.
This module emphasizes simplicity and reliability, making it ideal for systems requiring straightforward analog output control with high operational dependability.
Technical Specifications
| Parameter | Details |
|---|
| Model | IS200STAOH2A |
| Module Type | Simplex Analog Output Terminal Board |
| Series | GE Mark VI Speedtronic |
| Output Channels | 8 Channels (configurable) |
| Output Range | ±10 V, 4–20 mA |
| Resolution | 16-bit DAC |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel galvanic isolation |
| Indicators | LED status indicators for each channel |
| Operating Temperature | -20°C to 65°C |
| Mounting | Rack-mounted (Innovation Series) |
| Dimensions (HxWxD) | Approx. 160 x 120 x 40 mm |
| Weight | Approx. 0.7 kg |
Typical Applications
The IS200STAOH2A is widely used in industrial automation and turbine control environments where precise analog output is critical:
-
Gas and steam turbine control systems
-
Power generation plants
-
Oil & gas processing facilities
-
Chemical and petrochemical plants
-
Large-scale industrial automation systems
It ensures consistent analog output to control field devices, enabling reliable process regulation.
Technical FAQs
1. How many analog output channels does this board provide?
It provides 8 configurable analog output channels.
2. What signal types are supported?
±10 V and 4–20 mA signals.
3. What is the resolution of the outputs?
It uses a 16-bit digital-to-analog converter for high precision.
4. Is the board isolated?
Yes, channel-to-channel galvanic isolation is provided.
5. Can it operate in industrial temperature ranges?
Yes, it operates reliably from -20°C to 65°C.
6. Does it offer diagnostic features?
Yes, LED indicators display channel status and faults.
7. What systems typically use this board?
Gas and steam turbines, power plants, and industrial automation systems.
8. How is the board installed?
It mounts directly into the Innovation Series backplane.
9. What devices does it control?
Actuators, control valves, and other analog-driven field equipment.
10. Is it compatible with other Mark VI modules?
Yes, it integrates fully within the Mark VI Speedtronic platform.
