Overview
The GE IS200STAIH2ACB Analog I/O Terminal Board is an essential component of the Mark VI Speedtronic control system, providing a reliable interface for analog signals between field devices and the central control system. Designed for industrial-grade turbine and process automation applications, this board ensures accurate signal conditioning, stable transmission, and dependable system performance.
Its robust construction and user-friendly diagnostics allow for quick maintenance while maintaining system uptime, making it an ideal solution for critical power generation and industrial process environments.
Technical Specifications
| Parameter | Details |
|---|
| Model | IS200STAIH2ACB |
| Module Type | Analog I/O Terminal Board |
| Series | GE Mark VI Speedtronic |
| Channels | 16 Analog Inputs / Outputs (configurable) |
| Input Range | ±10 V, 4–20 mA |
| Output Range | ±10 V, 4–20 mA |
| Resolution | 16-bit DAC/ADC |
| Accuracy | ±0.1% of full scale |
| Isolation | Galvanic isolation between channels |
| Operating Temperature | -20°C to 65°C |
| Mounting | Rack-mounted (Innovation Series) |
| Dimensions (HxWxD) | Approx. 160 x 120 x 40 mm |
| Weight | Approx. 0.75 kg |
| Indicators | LED status indicators for signal and fault |
Application Scenarios
This terminal board is widely used in industrial automation systems where precision analog measurement and control are essential:
-
Gas and steam turbine control systems
-
Power generation plants
-
Oil & gas process control
-
Large-scale industrial automation
-
Water and wastewater treatment facilities
It provides consistent analog input and output interfaces to ensure accurate control of actuators, valves, and sensors throughout the system.
Technical FAQs
1. How many channels does this board support?
It provides 16 configurable analog I/O channels.
2. What types of signals can it handle?
It supports ±10 V and 4–20 mA for both input and output.
3. What is the resolution of the analog signals?
It uses 16-bit DAC/ADC conversion for precise signal processing.
4. Is the board isolated?
Yes, each channel is galvanically isolated to prevent interference.
5. Can it be used in harsh environments?
Yes, it operates reliably between -20°C to 65°C.
6. Does it provide diagnostic indicators?
Yes, LEDs indicate channel status and faults.
7. What types of systems use this terminal board?
Gas/steam turbines, power plants, and industrial automation systems.
8. How is it mounted?
It is rack-mounted in Innovation Series backplanes.
9. What is its role in system control?
It provides a precise interface between analog field devices and the control system.
10. Is it compatible with other Mark VI modules?
Yes, it integrates fully within the Mark VI Speedtronic ecosystem.
