Intuitive Operator Interface for Industrial Control
The Schneider XBTG2110 Touch Screen Panel is a rugged human‑machine interface (HMI) designed for real‑time visualization, command input, and operational monitoring in industrial environments. With its responsive touch interface and clear graphics, it enables operators to interact directly with PLC systems, view process data, adjust setpoints, and respond to alarms—all from a compact and durable panel.
Built for control panels, machine interfaces, and distributed automation systems, the XBTG2110 combines ease of use with reliable performance to enhance operational visibility and control.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Touch Screen HMI Panel |
| Model Number | XBTG2110 |
| Display Size | 5.7 inches |
| Display Type | TFT Color Touch Screen |
| Resolution | 320 × 240 pixels |
| Touch Technology | Resistive Touch |
| Communication Ports | RS‑232, RS‑485, Ethernet (optional) |
| Supported Protocols | Modbus, Modbus TCP/IP, Schneider protocols |
| Power Supply | 24 V DC |
| Backlight | LED |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | ‑20°C to 70°C |
| Relative Humidity | 10–90% non‑condensing |
| Mounting | Panel mount (cut‑out) |
| Dimensions (HxWxD) | Approx. 150 × 105 × 50 mm |
| Weight | Approx. 0.55 kg |
| Protection Rating | IP54 (front) |
Application Scenarios
The XBTG2110 is widely used in applications where reliable operator interaction and process visibility are essential. Typical uses include:
-
Machine Control Panels: Displaying real‑time machine status, process variables, and operator commands.
-
Packaging and Material Handling: Visualizing production rates, status indicators, and alarms.
-
Water & Wastewater Systems: Monitoring system performance and adjusting control parameters locally.
-
Building Automation: Providing interface for HVAC, lighting, and access systems.
-
OEM Equipment Integration: Embedding an intuitive interface into customized machinery.
Its compact footprint and intuitive touch interface make it a good fit for mediumsized equipment and control panels where ease of use is a priority.
Key Advantages and Benefits
-
User‑Friendly Touch Interface: The responsive resistive screen allows straightforward interaction, even with gloves.
-
Clear Visual Feedback: Color display and customizable screens provide clear process information.
-
Flexible Communication: Multiple ports and supported protocols enable seamless integration with PLCs and supervisory systems.
-
Rugged Industrial Design: IP54 front protection and industrial‑grade components support reliable operation in factory environments.
-
Compact Form Factor: Fits into space‑constrained panels while delivering essential control and monitoring functions.
This panel enhances operator effectiveness, improves situational awareness, and supports faster response to process changes or alarms.
Technical FAQs
1. What is the display size of the XBTG2110?
It features a 5.7‑inch color touch screen.
2. What touch technology does it use?
Resistive touch for reliable user interaction.
3. What communication protocols does it support?
Modbus, Modbus TCP/IP, and Schneider protocols over serial or Ethernet.
4. What is the operating temperature range?
0°C to 50°C.
5. How is the panel mounted?
Panel mount with standard cut‑out dimensions.
6. Does it support Ethernet communication?
Yes, Ethernet is supported on applicable variants.
7. What protection rating does it provide?
Front panel protection at IP54 for dust and splashes.
8. Can it display alarms and historical values?
Yes, configurable screens allow alarm lists and trends.
9. What power supply is required?
24 V DC power input.
10. In which industries is it commonly used?
Manufacturing, material handling, water treatment, building automation, and OEM machine control.
