Industrial Ethernet Connectivity for Seamless Data Exchange
The Schneider TSXSUP1051 Ethernet TCP/IP Module is a dedicated communication interface designed to integrate Modicon PLC systems into modern industrial Ethernet networks. It enables high-speed data exchange between controllers, SCADA systems, HMIs, and remote devices—supporting real-time monitoring, diagnostics, and control.
With its robust design and reliable protocol support, this module is an excellent solution for facilities transitioning from traditional serial communication to Ethernet-based automation architectures.
Technical Specifications
| Parameter | Specification |
|---|
| Product Type | Ethernet TCP/IP Communication Module |
| Model Number | TSXSUP1051 |
| Communication Interface | Ethernet (RJ45) |
| Transmission Speed | 10/100 Mbps |
| Supported Protocols | Modbus TCP/IP, Ethernet TCP/IP |
| Network Topology | Star / Industrial Ethernet |
| Max Connections | Up to 64 simultaneous sessions |
| Power Supply | Via PLC rack backplane |
| Current Consumption | Approx. 530 mA @ 5 V DC |
| Diagnostic Indicators | LED status (RUN, ERR, TX/RX, LINK) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Humidity Range | 5–95% non-condensing |
| Dimensions (HxWxD) | Approx. 260 × 180 × 60 mm |
| Weight | Approx. 0.34 kg |
| Mounting | Rack-mounted within PLC chassis |
Application Scenarios
The TSXSUP1051 module is widely used in industrial environments where Ethernet communication is essential for system integration and real-time data exchange.
In manufacturing plants, it connects PLCs to SCADA systems for centralized monitoring and control. In process industries such as chemical or water treatment, it enables remote diagnostics and data acquisition. It is also commonly deployed in energy and utilities systems where distributed devices must communicate over Ethernet networks.
Additionally, OEM machine builders use this module to integrate their equipment into factory-wide networks, enabling predictive maintenance and improved production visibility.
Key Advantages and Value
The TSXSUP1051 stands out for delivering reliable industrial Ethernet communication with minimal configuration complexity. Its support for Modbus TCP/IP ensures compatibility with a wide range of third-party devices and systems, allowing seamless integration across heterogeneous environments.
The module’s ability to handle multiple simultaneous connections makes it ideal for systems requiring concurrent data exchange with SCADA, HMIs, and remote clients.
Integrated diagnostic LEDs provide clear visibility into network status, helping engineers quickly identify and resolve communication issues. Its rugged construction ensures stable operation even in environments with electrical noise, vibration, and temperature fluctuations.
By enabling Ethernet-based communication, this module reduces wiring complexity, enhances scalability, and supports modern digitalization strategies within industrial automation systems.
Technical FAQs
1. What is the primary function of the TSXSUP1051?
It enables Ethernet TCP/IP communication between PLCs and networked devices.
2. Which protocols are supported?
Modbus TCP/IP and standard Ethernet communication protocols.
3. What is the communication speed?
10/100 Mbps auto-negotiation Ethernet.
4. How many devices can connect simultaneously?
Up to 64 concurrent connections depending on configuration.
5. Does it require an external power supply?
No, it is powered directly from the PLC rack.
6. What diagnostics are available?
LED indicators for network activity, errors, and connection status.
7. Can it be used with SCADA systems?
Yes, it is commonly used for SCADA and HMI integration.
8. Is it suitable for remote monitoring?
Yes, Ethernet connectivity enables remote diagnostics and control.
9. What environments can it operate in?
Industrial environments from 0°C to 60°C with high humidity tolerance.
10. Does it support integration with third-party devices?
Yes, via standard Modbus TCP/IP communication.
